Check for misalignment and seizure of moving
parts, breakage of parts and any other conditions
that may affect its operation. Have damaged
guards or other defective parts repaired or
replaced as instructed.
Do not use the tool if the switch is defective.
Have the switch replaced by an authorized
DEWALT repair agent.
20 Have your tool repaired by an authorized
DEWALT repair agent
This Power Tool is in accordance with the
relevant safety regulations. To avoid danger,
electric appliances must only be repaired by
qualified technicians.
Package contents
The package contains:
1 Rotary hammer
1 Side handle
1 Depth adjustment rod
1 Tube of bit lubricant
1 Kitbox (K-models only)
1 Instruction manual
1 Exploded drawing
• Check for damage to the tool, parts or accessories
which may have occurred during transport.
• Take the time to thoroughly read and understand
this manual prior to operation.
Description (fig. A)
Your D25500/D25600 rotary hammer has been
designed for professional hammer drilling and light
chipping, chiselling and demolition applications.
1 On/off switch
2 Electronic speed and impact control dial
3 Service indicator LED (D25600)
4 Mode selector switch
5 Safety lock
6 Tool holder
7 Collar
8 Side handle
9 Side handle clamp wheel
10 Rear side handle position
11 Depth adjustment rod
12 Rear handle
Soft start feature
The soft start feature allows to build up speed slowly,
thus preventing the drill bit from walking off the
intended hole position when starting. The soft start
feature also reduces the immediate torque reaction
transmitted to the gearing and the operator if the
hammer is started with the drill bit in an existing hole.
Torque limiting clutch
The torque limiting clutch reduces the maximum
torque reaction transmitted to the operator in case
of jamming of a drill bit. This feature also prevents
the gearing and electric motor from stalling.
The torque limiting clutch has been factory-set and
cannot be adjusted.
Electronic speed and impact control (fig. B)
The electronic speed and impact control (2) offers
the following advantages:
- use of smaller accessories without risk of breakage
- minimised break-out when chiselling or drilling in
soft or brittle materials
- optimal tool control for precise chiselling
Service indicator LED (fig. B)
The red service indicator LED (3) lights up when the
carbon brushes are nearly worn out to indicate that
the tool needs servicing. After a further 8 hours of
use the motor will automatically be shut off.
The carbon brushes are not user-serviceable.
Take the tool to an authorized DEWALT repair agent.
Electrical safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your DEWALT tool is double insulated in
accordance with EN 50144; therefore no
earth wire is required.
Mains plug replacement
(U.K. & Ireland only)
• Should your mains plug need replacing and you
are competent to do this, proceed as instructed
below. If you are in doubt, contact an authorized
DEWALT repair agent or a qualified electrician.
• Disconnect the plug from the supply.

DeWalt D25600 Specifications

General

Brand	DeWalt
Model	D25600
Category	Rotary Hammer
Language	English
