6
ENGLISH
Side Handle (Fig.B)
WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximizecontrol.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Active Vibration Control (AVC) System
For best vibration control, hold the tool as described in Proper
Hand Position and apply just enough pressure so the damping
device on the main handle is approximately midstroke.
The active vibration control neutralises rebound vibration from
the hammer mechanism. Lowering hand and arm vibration,
it allows more comfortable use for longer periods of time and
extends the life of theunit.
The hammer only needs enough pressure to engage the active
vibraton control. Applying too much pressure will not make the
tool chip faster and active vibration control will notengage.
Tool Tag Ready (Fig. A)
Optional Accessory
Your hammer comes with
tool tag mounting holes
9
and fasteners for installing a
Tool Tag. You will need a
T20 bit tip to install the tag. The
Tool Tag is designed
for tracking and locating professional power tools, equipment,
and machines using the
Tool Connect™ app. For proper
installation of the
Tool Tag refer to the
Tool
Tagmanual.
Electronic Speed and Impact Control (Fig.A)
The electronic speed and impact control allows optimal tool
control for precisechiseling.
To set the electronic speed and impact control dial
8
, turn the
dial to the desired level. The higher the number, the greater
the speed and impact energy. Dial settings make the tool
extremely flexible and adaptable for many different appli cations.
The required setting depends on the bit size and hardness of
material beingchiseled.
• When chiselling soft, brittle materials or when minimum
break-out is required, set the dial to a low setting;
• When breaking harder materials, set the dial to a
highsetting.
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
ON/OFF rocker switch
2
Side handle
3
Front Barrel (Collar)
4
Mode selector dial
5
Main handle
6
Tool holder
7
Locking sleeve
8
Electronic speed and
impact control dial
9
tool tag mounting
holes
10
Screw for side handle
mounting
11
Date code
Intended Use
Your chipping hammer has been designed for professional
chiseling and chippingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your chipping hammer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig. A)
The date code
11
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Package Contents
The package contains:
1 Chipping hammer
1 Side handle
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
