COMPONENTS (Fig. 2)
WARNING: Never modify the power tool or any part of it. Damage
or personal injury could result.
A. Battery release buttons
B. Rocker switch (DC800)
C. Trigger switch
(DC810, DC815)
D. Forward/reverse button
(DC810, DC815)
E. Detent pin (DC800, DC810)
F. Anvil (DC800, DC810)
G. Battery pack
INTENDED USE
These heavy-duty impact wrenches are designed for professional
impact screwdriving applications. The impact function makes this
tool particularly useful for driving fasteners in wood, metal and
concrete.
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
These heavy-duty impact wrenches are professional power tools.
DO NOT let children come into contact with the tool. Supervision is
required when inexperienced operators use this tool.
OPERATION
WARNING: To reduce the risk of injury, turn unit off
and disconnect it from power source before installing and
removing accessories, before adjusting or when making
repairs. An accidental start-up can cause injury.
FIG. 2
B
DC800 DC810
D
C
DC815
D
C
F
E
F
E
A A
A
G
G
G
