DeWalt DCC020IB User Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
LED worklight
2
Power switch
3
Inflation mode switch
4
LED light switch
5
High-volume hose
6
Pressure adjustment
knob
7
Inflation start/pause
button
8
Pressure setting/mode
display
9
Pressure gauge display
10
High-pressure hose
11
Battery release button
12
Battery pack
13
High-volume tapered
nozzle
14
Inlet/Deflation port
15
High-pressure tapered
nozzle
16
Inflator needle
17
Presta valve adapter
18
Outlet/Inflation port
19
12V DC vehicle
connector and cord
20
External power
connector (12V DC or
ACadapter)
Fig. A
1
2
3
4
6
8
9
10 11 12 13
1
14
15
19
20
16
17
18
7
5

DeWalt DCC020IB Specifications

General

Voltage	20V
Type	Inflator
Max Pressure	160 PSI
Digital Gauge	Yes
Auto Shutoff	Yes
Power Source	Battery
Battery Type	Lithium-Ion
