DeWalt DCD701 Original Instructions

ENGLISH
3
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
EC-Declaration of Conformity
Machinery Directive
Sub-Compact Drill/Driver/Hammerdrill
DCD701, DCD706
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-1:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
06.17.2019
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN60745 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
DCD701 DCD706
Voltage
V
DC
12 12
Type
1
1
Battery type
Li-Ion Li-Ion
Power output
W 250 250
No-load speed
1st gear
min
-1
0–425 0–425
2nd gear
min
-1
0–1500 0–1500
Beats per minute
1st gear
- 0–7225
2nd gear
- 0–25500
Max. Torque (hard/soft)
Nm 57.5/25.5 57.5/25.5
Chuck capacity
mm 10 10
Maximum drilling capacity
Wood
Metal
Masonary
mm
mm
mm
20
10
-
20
10
10
Weight (without battery pack)
kg 0.87 0.96
Noise values and/or vibration values (triax vector sum) according to
EN60745-2-1:
L
PA
(emission sound pressure level) dB(A) 72 83
L
WA
(sound power level) dB(A) 83 94
K (uncertainty for the given
sound level)
dB(A) 3 3
Drilling into metal
Vibration emission value a
h,D
= m/s
2
2.5 3.1
Uncertainty K = m/s
2
1.5 1.5
Drilling into concrete
Vibration emission value a
h,ID
= m/s
2
- 15.5
Uncertainty K = m/s
2
- 4
Screwdriving
Vibration emission value a
h
= m/s
2
< 2.5 <2.5
Uncertainty K = m/s
2
1.5 1.5
English (original instructions)
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
SUBCOMPACT DRILL/DRIVER/HAMMERDRILL
DCD701, DCD706

DeWalt DCD701 Specifications

General

Voltage	12V
Max RPM	1500 RPM
Chuck Size	3/8 in
Battery Type	Lithium-Ion
Tool Length	5.97 in
No Load Speed (RPM)	0-425 / 0-1500 RPM
