Plunger Rod Handle (Fig. A)

WARNING: To reduce the risk of serious personal
injury, DO NOT use the plunger rod handle as a hook to
suspend objectsfrom.
The plunger rod handle
4
may be used to suspend tool from a
stable location when not in use or for storage.
To Adjust Plunger Rod (Fig. A)
1. To manually adjust plunger rod
5
, press and hold the
plunger rod release trigger
6
.
2. Push or pull plunger rod handle
4
to desirableposition.
3. Release plunger rod releasetrigger.
To Insert Material
Cartridge Holder (Fig.A, I)
1. Ensure that plunger used is appropriate tomaterial.
NOTE: Using incorrect plunger may result in material
container exploding during use, damaging cartridge holder
and/or caulkgun.
2. Use the trigger switch lock-off
2
to lock trigger switch
1
.
3. Trim nozzle end of the caulk/material tube (Fig.I). Small
openings require more force to push the material possibly
affecting batterylife.
4. Break inner seal of caulking tube or material using the poker
9
located on the under side of the cartridgeholder.
NOTICE: If the inner seal is not broken, material could
be forced out through the rear of the tube and damage
thetool.
NOTICE: Keep plunger rod, cartridge holder and cartridge
clean of all material. Retracting a plunger rod that is
covered with dried material may damage the internal
parts of the tool and cause misalignment oftube.
5. Securely hold the tool, press plunger rod release trigger
6
to declutch and free the plunger rod
5
. Using the plunger
rod handle
4
, pull the plunger rod back to allow the caulk/
material tube to fit inside the cartridgeholder.
6. Insert caulk/materialtube.
7. Press and hold plunger rod release trigger
6
while pushing
the plunger rod handle
4
forward until the plunger
7
is
against thetube.
8. Release the plunger rod releasetrigger.
9. Rotate cartridge holder to desiredangle.
Sausage Holder (Fig.A, H, I)
1. Ensure that plunger used is appropriate tomaterial.
NOTE: Using incorrect plunger may result in material
container exploding during use, damaging cartridge holder
and/or caulkgun.
2. Unscrew and remove nozzle cap
13
. andnozzle.
3. Press and hold plunger rod release trigger
6
. Using the
plunger rod handle
4
, pull plunger rod
5
back to allow the
caulk/material casing to fit inside the sausageholder
12
.
4. Insert sausage pack into sausage holder and cut casing
(closest end to the nozzle) according to material
manufacturer's instructions.
IMPORTANT: DO NOT remove caulk/material material
from the casing. NEVER dip the nozzle tip into any type
ofmaterial.
5. With nozzle tip facing away from tool, screw nozzle cap
back onto sausageholder.
6. Trim tip of nozzle for appropriate application (Fig.I).
NOTE: Material left in the cartridge/sausage holder may dry if
left unattended. Follow manufacturer’s recommendations when
using caulk or adhesivematerial.
MAINTENANCE
Your DEWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning (Fig. A)

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
NOTICE: Material left in the cartridge/sausage holder may
dry if left unattended. Do not attempt to dispense material
under this condition. Follow the adhesive manufacturer's
recommendations when using caulk or adhesive material
to reduce the risk of propertydamage.
To clean the cartridge holder, follow adhesive manufacturer's
recommendations for cleaning material from nozzle, barrel
plunger and plungerrod.
To clean the sausage holder, unscrew nozzle cap
13
and
sausage holder
12
and remove from tool. Follow the adhesive
manufacturer's recommendations for cleaning material from
nozzle, barrel plunger, plunger rod and sausageholder, along
with any instructions provided on accessory component labels
anddocuments.
