DeWalt DCG409VS User Manual

4
ENGLISH
EC‑Declaration of Conformity
Machinery Directive and Radio Equipment
Directive
o
Cordless Small Angle Grinder
DCG409VS, DCG416VS
D
EWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN62841-2-3:2021 +A11:2021.
These products also comply with Directive 2014/53/EU and
2011/65/EU. For more information, please contact D
EWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofD
EWALT.
Markus Rompel
Vice-President Engineering, PTE-Europe
D
EWALT, Richard-Klinger-Straße 11,
65510, Idstein, Germany
01.07.2022

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.

WARNING : Grinding thin sheets of metal or other easily
vibrating structures with a large surface can result in a
total noise emission much higher (up to 15dB) than the
declared noise emission values. Such workpieces should
as far as possible be prevented from emitting sound by
suitable measures such as the application of heavy flexible
damping mats. The increased noise emission is also to be
considered for both the risk assessment of noise exposure
and selecting adequate hearingprotection.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in
EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
DCG409VS DCG416VS
Voltage V
DC
18 18
Type 1 1
Battery type Li‑Ion Li‑Ion
Max. Power Output W 1450 1450
Rated speed min
‑1
9000 9000
No load speed min
‑1
3000–9000 3000–9000
Wheel diameterº mm 125 125
Wheel thickness (max) mm 6 6
Wire wheel thickness (max) mm 16 16
Spindle diameter M14 M14
Spindle length mm 21.5 21.5
Wireless Tool Control Transmitter
Frequency Band
Max. Power (EIRP)
MHz
mW
433
0.03
433
0.03
Weight (without battery pack) kg 1.85 1.85
Noise values and/or vibration values (triax vector sum) according to EN62841‑2‑3:
L
PA
(emission sound pressure level) dB(A) 85 86
L
WA
(sound power level) dB(A) 93 94
K (uncertainty for the given sound level) dB(A) 3 3
Surface grinding
Vibration emission value a
h,AG
= m/s
2
6.9 8.3
Uncertainty K = m/s
2
1.5 1.5
Disc sanding
Vibration emission value a
h,DS
= m/s
2
2.9 <2.5
Uncertainty K = m/s
2
1.5 1.5
Concrete grinding
Vibration emission value a
h,CG
= m/s
2
6.6 7.3
Uncertainty K = m/s
2
1.5 1.5
Cutting off
Vibration emission value a
h,CO
= m/s
2
6.6 7.3
Uncertainty K = m/s
2
1.5 1.5
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough
product development and innovation make D
EWALT one of the
most reliable partners for professional power toolusers.
Technical Data
SMALL ANGLE GRINDER
DCG409VS, DCG416VS
