9
ENGLISH
Switch (Fig. A)
To turn the light on, press the switch
3
. To turn it off, press the
switch again.
Low Battery Indicator
As the battery nears a fully discharged state, the light will blink
twice and then dim, dropping the brightness of the light below
the normal level. The light will continue to blink twice every 45
seconds until the battery is fully discharged at which time the
light will turn off. Indication time will vary based on battery pack
capacity.
Magnets, Belt Hook and Stand (Fig. A)
CAUTION: When magnets, belt hook or stand is in use,
do not shake light. Personal injury or property damage
may occur.
CAUTION: When light is hung by the magnets, belt hook
or stand, do not shake the light or object that it is hanging
from. Do not hang the light from any electrical wires or
anything that is not secure. Personal injury or property
damage may occur.
CAUTION: Only use the magnets, belt hook or stand for
hanging the LED worklight. The magnets, belt hook or
stand are not intended to support additional weight. Do
not attach or hang anything additional to the light or risk
of breakage may occur.
CAUTION: Do not use the magnets, belt hook or stand to
reach with or use the magnet and belt hook to support
your weight in any situation.
CAUTION: Do not stand underneath a hanging light.
Using the stand
6
, belt hook
7
and magnets
8
, the worklight
can be placed in multiple locations for ideal lighting.
The stand should be snapped into the home position if not in
use, as shown in FigureA.
Pivoting Head (Fig. E)
The light head pivots vertically 180˚ and rotates horizontally
180˚, allowing the light beam to be angled in any direction.
Replacing the Lens (Fig. F)
If the lens becomes damaged, an accessory lens is available at
extra cost from an authorized service centre. To replace the lens,
first remove the battery.
1. Remove 2 screws
9
from the bezel
10
.
2. Separate the 2 halves of the bezel.
3. Remove the lens
5
.
4. Attach the new lens, reattach the 2 halves of the bezel and
secure in place screws. Do not overtighten.
MAINTENANCE
Your
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn worklight off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed of properly.
