DeWalt DCL070T1 - Light Control, Maintenance, and Accessories; Light Direction Control; Low Battery Indicator; AC Outlet, Security Tabs, and Moving the Area Light

ENGLISH
9
maximum brightness. Press and hold the brightness down
button
4
to go directly to minimum brightness.
Pressing the brightness up button
3
while at maximum
brightness will go directly to minimum brightness.
Pressing the brightness down button
4
while at minimum
brightness will go directly to maximum brightness.
Light Direction
To turn the left half of the light on or off, press the left light
on/off button
5
. To turn the right half of the light on or off,
press the right light on/off button
6
.
Low Battery Indicator
As the battery nears a fully discharged state, the light will
blink twice and then dim, dropping the brightness of the
light below the normal level. The light will continue to blink
twice every 45 seconds until the battery is fully discharged
at which time the light will turn off. Indication time will vary
based on battery pack capacity.

WARNING: Stop work and replace the battery or
connect the area light to AC when this occurs.
AC Outlet/AC Plug (Fig. A)
An extension cord can be plugged into the AC plug
9
then into a wall outlet to power the area light and charge
the battery. An AC outlet is available to connect extension
cords to additional lights or for powering additional tools or
appliances.
NOTE: The AC outlet cannot be controlled by the Tool
Connect™ app.

WARNING: Do not connect devices drawing more
than 10 amps.

WARNING: Do not connect more than 4 area
lightstogether.

CAUTION: The area light's AC outlet is "live" when
the area light is plugged into a wall outlet. The AC
outlet is not controlled by buttons or by the Tool
Connect™app.
Securing the Area Light
Two security tabs
10
are available on the base of the area
light to lock it with a chain or to keep multiple area lights
secured together.
Moving the Area Light
Two handles
12
are provided for safely carrying your area
light. The feet
11
on the area light can accommodate four
standard 3" (76 mm) diameter casters with 3/8-16 UNC
threaded studs (1-3/4" [45 mm] maximum stud length) with
a minimum 100 lb weight capacity. At least one caster must
be of a locking type. Accessory
DeWALT
casters are available
on www.dewalt.com.
MAINTENANCE

WARNING: To reduce the risk of serious personal
injury, turn area light/charger off, remove
battery pack and disconnect from the AC outlet
before making any adjustments, removing/
installing attachments or accessories, and
beforecleaning.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performingthis.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Do not clean this area
light with a water spray or the like; never immerse any
part of the area light in a liquid.
Accessories

WARNING: Since accessories, other than those
offered by
DeWALT
, have not been tested with this
product, use of such accessories with this tool could be
hazardous. To reduce the risk of injury, only
DeWALT
recommended accessories should be used with
thisproduct.
Recommended accessories for use with your tool
are available at extra cost from your local dealer or
authorized service center. If you need assistance in
locating any accessory, please contact
DeWALT
Industrial
Tool Co., 701East Joppa Road, Towson, MD 21286, call
1-800-4-
DeWALT
(1-800-433-9258) or visit our website:
www.dewalt.com.
Repairs
The battery pack is notserviceable.

WARNING: To assure product SAFETY and
RELIABILITY, repairs, maintenance and adjustment
(including brush inspection and replacement) should
be performed by a
DeWALT
factory service center
or a
DeWALT
authorized service center. Always use
identical replacementparts.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of
an insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
ofpurchase.
• FOR YOUR SAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
SafetyAct.
Register online at www.dewalt.com/register.
Three Year Limited Warranty
DeWALT
will repair, without charge, any defects due to
faulty materials or workmanship for three years from the
date of purchase. This warranty does not cover part failure
