3. Insert a screwdriver back through the three
holes (x, z, and aa) and thread the new spool
housing counterclockwise and securely tighten
onto the bolt (bb) protruding from the trimmer.
Replacing Guard (fig. 16–18)
WARNING: Never operate
appliance without guard firmly in place
.
1. Remove the spool housing as described in the
Replacing Spool Housing section.
2. Remove the 4 guard screws (cc) shown in
Figure 16.
3. Lift the guard off at an angle as shown in
Figure 17.
4. To attached a new guard, slide the tab (dd) of
the new guard under the lip (ee) of the motor
housing (e), then lower the back of the guard
into place as shown in Figure 18.
5. Replace and securely tighten the 4 guard
screws (cc).
6. Replace the spool housing as described in the
Replacing Spool Housing section.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust
out of the main housing with dry air as
often as dirt is seen collecting in and
around the air vents. Wear approved
eye protection and approved dust mask
when performing this procedure.
WARNING: Never use solvents
or other harsh chemicals for cleaning
the non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.
holes (t) on either side of the head in the spool
housing (h) as shown in Figure 12.
12. Line up the white nubs (u) inside the spool
housing with the recesses (v) of the spool. Align
the holding slots (s) with the two holes (t) as
close as possible.
13. Push the spool into the spool housing and
turn counterclockwise to lock the spool in
place. Ensure the white nub (u) appears in the
spool window (p). Make sure the line doesn't
unravel and wrap around the shaft below the
spool.
14. Pull both ends of the cutting line to release
them from the holding slots. If the line extends
past the cutting blade on the guard cut the line
so it just reaches the blade.
MAINTENANCE
Your D
WALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular
cleaning.
WARNING: To reduce the risk
of serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up can
cause injury.
1. Keep the air intake slots (w), shown in
Figure 13, clean to avoid overheating.
2. Your trimmer line can dry out over time. To
keep your line in top condition, store spare line
in a plastic, sealable bag with a tablespoon of
water.
3. Plastic parts may be cleaned by using a mild
soap and a damp rag.
4. The line cutter on the edge of the guard
can dull over time. It is recommended you
periodically touch-up the sharpness of the
blade with a file.
The charger and battery pack are not serviceable.
Replacing Spool Housing (fig. 14, 15)
1. Rotate the spool housing (h) until the hole (x)
in the spindle (y) lines up with notch (z) in the
guard (g). A third hole in the motor housing
(aa) will be visible as shown in Figure 14. Insert
screwdriver through all three holes to prevent
the spool housing from turning.
2. Turn the spool clockwise as shown in Figure 15.
