DeWalt DCN45RNN Original Instructions

14
ENGLISH
Replacing the Profile (Fig.N)
To Change a Broken or Worn Profile
1. Refer to Return Spring Replacement Steps 1–4 to remove
the return system from the unit and to remove thesprings.
2. Take note of the orientation of the profile
24
. Slide the
profile off therail
20
3. In the same orientation as the old profile, slide the new
profile onto therails.
4. Refer to Return Spring Replacement Steps 5–7 to complete
theservice.
NOTE: Check the return of the profile by sliding the profile
up the spring rail and letting it go. It should return due to
the force from thesprings.
7. Slide the return system
18
back into the unit. It is important
to try the alignment of the profile and the flywheel before
screwing the return system back on to the unit. This can be
done by connecting a battery and pushing then releasing
the nose of the unit against a bench or hard surface. This will
start the motorspinning.
NOTE: When the profile and the flywheel are correctly
aligned, you will hear the motor coast back down from
full speed. If the profile and the flywheel are not correctly
aligned the motor it may not start up, may slow down
much faster than normal along with a loud grinding
noise from the unit. If this happens remove and reseat the
returnsystem.

WARNING: Always test the unit by firing short nails in
to soft wood, to ensure that the tool is working properly.
If tool does not operate properly, contact a recognized
DEWALT service centreimmediately.
Protecting the Environment
w
Separate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that
can be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li‑Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
