DeWalt DCN680 User Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings
and allinstructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or seriousinjury.
WARNING: To reduce the risk of injury, read
the instructionmanual.
If you have any questions or comments about
this or any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Trigger
2
Trigger lock-off
3
Depth adjustment wheel
4
Headlights/Low battery/
Stallindicator
5
Jam clearing latch
6
Contact trip
7
Sliding magazine
8
Bump/Sequential
selectorswitch
9
Reversible belt hook
10
No-mar pad
11
No-mar pad storage
12
Stall release lever
13
Nail depth indicator
14
Battery
15
Battery release button
16
Magazine latch
17
Low nail indicator
Fig. A
11
3
13
1
2
4
15
14
9
8
12
7
17
16
56
10

DeWalt DCN680 Specifications

General

Type	Brad Nailer
Gauge	18 gauge
Magazine Capacity	110 nails
Tool-Free Jam Release	Yes
Magazine Angle	Straight
Firing Mode	Sequential
Dry Fire Lockout	Yes
Sequential Trigger	Yes
Nail Length	5/8" to 2-1/8"
Power Source	Battery
Depth Adjustment	Yes
