ENGLISH
47
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.
Battery pack DCB180 DCB181 DCB182
Battery type Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18
Capacity Ah 3.0 1.5 4.0
Weight kg 0.64 0.35 0.61
Battery pack DCB183 DCB184 DCB185
Battery type Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18
Capacity Ah 2.0 5.0 1.3
Weight kg 0.4 0.62 0.31
Charger DCB105
Mains voltage V
AC
230 V
Battery type Li-Ion
Approximate min 25 30 40
charging time (1.3 Ah) (1.5 Ah) (2.0 Ah)
of battery packs 55 70 90
(3.0 Ah) (4.0 Ah) (5.0 Ah)
Weight kg 0.49
Fuses
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 3 Amperes, in plugs
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
MACHINERY DIRECTIVE
CORDLESS FRAMING NAILER
DCN690, DCN691, DCN692
DEWALT declares that these products described
under Technical Data are in compliance with:
2006/42/EC, EN 60745-1, EN 60745-2-16.
These products also comply with Directive
2004/108/EC and 2011/65/EU. For more
information, please contact DEWALT at the following
address or refer to the back of the manual.
The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf of
DEWALT.
Horst Grossmann
Vice President Engineering
DEWALT, Richard-Klinger-Strasse 11,
D-65510, Idstein, Germany
31.01.2014
WARNING: To reduce the risk of injury,
read the instruction manual.
General Power Tool Safety Warnings
WARNING! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result
in electric shock, fire and/or serious
injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
