DeWalt DCR006 - Speaker Functionality; Powering and Pairing; Powering the Speaker On and Off

Page dimensions: 8.5 x 5.5 inches
10
English
OR
OU
O
FIG. 6
F
OR
POWERING THE SPEAKER ON AND OFF (FIG. 7)
Pressing the power button (A) will turn the speaker on or off. When
turned on, the LED indicator (B) will indicate the speaker's status.
Upon initial use, the speaker will require pairing. To pair speaker to
a Bluetooth
®
device refer to Pairing Speaker with a Bluetooth
®
Audio Device.
FUEL GAUGE BATTERY PACKS (FIG. 5)
Some D
EWALT battery packs include a
fuel gauge which consists of three green
LED lights that indicate the level of charge
remaining in the battery pack.
To actuate the fuel gauge, press and hold
the fuel gauge button (K). A combination
of the three green LED lights will illuminate
designating the level of charge left. When
the level of charge in the battery is below
the usable limit, the fuel gauge will not
illuminate and the battery will need to be
recharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate apparatus functionality and is
subject to variation based on product components, temperature and
end-user application.
For more information regarding fuel gauge battery packs, please
call 1-800-4-D
EWALT (1-800-433-9258) or visit our website
www.dewalt.com.
Functionality (Fig. 6, 7)
Audio can be played through the speaker via a wireless Bluetooth
®
connection to a compatible Bluetooth
®
device or by connecting audio
device or mobile phone using a 1/8' (3.5 mm) audio cable to the
audio port (F).
K
FIG. 5
