DeWalt DCS356N

35
ENGLISH
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
1
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
Installing/Removing Accessories (Fig.C–M,Q)
Tool-free Accessory clamp (Fig.C–E)
The DCS355, DCS356 features a quick change accessory system.
This allows for faster accessory changes without the need for
wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the accessory clamping lever
3
as shown in FigureC.
2. Clean any residual debris from the tool shaft and the
accessoryholder.
3. Slide the accessory between the shaft
22
and the accessory
holder making sure the accessory engages all eight pins on
the holder and is flush with the shaft. Ensure the accessory is
oriented as shown in FigureD.
4. Release the accessory clamplever.
NOTE: Some accessories, such as scrapers and blades can be
mounted at an angle if required as shown in FigureE.
Installing/Removing Sanding Sheets (Fig.F)
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets. The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen
23
as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet, with the edge of
the sanding platen and press the sanding sheet
24
onto
theplaten.
3. Firmly press the base with the sanding sheet attached
against a flat surface and briefly switch the tool on. This
provides for good adhesion between the platen and the
sanding sheet and also helps to prevent prematurewear.
4. When the tip of the sanding sheet becomes worn, detach
the sheet from the platen, rotate andreapply.
To Remove the Battery Pack from the Tool
1. Press the release button
2
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
11
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.

WARNING: Risk of lacerations or burns. Do not touch
the sharp edges of accessories at any time. Do not
touch workpiece or blade immediately after operating the
tool. They can become very hot. Handle carefully. Always
allow accessories and workpiece to cool beforehandling.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING: Use only DEWALT battery packs andchargers.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Variable speed trigger
2
LED Worklight
3
Accessory clamp lever
4
Lock on/off button
5
Accessory side mount slots
6
Cut guide block
7
Cut guide arm
8
Battery pack
9
Battery release button
10
Speed selector (DCS356)
Intended Use
This oscillating multi-tool is designed for professional detail
sanding, plunge cutting, flush cutting, removal of excess
materials and surface preparationapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This oscillating multi-tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
