DeWalt DCS727 User Manual

21
ENGLISH
Clamp: DW7090-XJ (Fig. C)
The clamp
39
is used for firmly clamping workpiece to the sawtable.
Optional Accessories

WARNING: Since accessories, other than those offered by
DeWALT
,
have not been tested with this product, use of such accessories with
this tool could be hazardous. To reduce the risk of injury, only
DeWALT
recommended accessories should be used with thisproduct.
Consult your dealer for further information on the appropriateaccessories.
Before use, carefully check the upper guard, lower guard and dust duct
to determine that they will operate properly. Ensure that chips, dust or
workpiece particles do not block of one of thefunctions.
In case of workpiece fragments jammed between the saw blade and
guards, remove the battery pack from the machine and follow the
instructions given in Changing or Installing a New Saw Blade. Remove
the jammed parts and reassemble the sawblade.
Periodically clean all dust and wood chips from around AND UNDER the
base and the rotarytable.
Worklight Cleaning
• Carefully clean sawdust and debris from worklight lens with a cotton
swab. Dust build-up can block the worklight and prevent it from
accurately indicating the line ofcut.
• DO NOT use solvents of any kind; they may damage thelens.
• With blade removed from saw, clean pitch and build-up fromblade.
Dust Duct Cleaning
With the saw unplugged and the saw head raised fully, low pressure air or a
large diameter dowel rod can be used to clear the dust out of the dustduct.
Cleaning

WARNING: Blow dirt and dust out of the main housing with dry air
as often as dirt is seen collecting in and around the air vents. Wear
approved eye protection and approved dust mask when performing
thisprocedure.

WARNING: Never use solvents or other harsh chemicals for cleaning
the non-metallic parts of the tool. These chemicals may weaken the
materials used in these parts. Use a cloth dampened only with water
and mild soap. Never let any liquid get inside the tool; never immerse
any part of the tool into aliquid.
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regularcleaning.

WARNING:To reduce the risk of serious personal injury, turn
tool off and disconnect battery pack before making any
adjustments or removing/installing attachments or accessories.
An accidental start-up can cause injury.
The charger and battery pack are notserviceable.
Inside Corner Outside Corner
Left side Bevel left 30°
Mitre table set at right 35.26°
Save left end of cut
Bevel right 30°
Mitre table set at left 35.26°
Save left end of cut
Right side Bevel right 30°
Mitre table set at left 35.26°
Save right end of cut
Bevel left 30°
Mitre table set at right 35.26°
Save right end of cut
4. The settings below are for crown moulding with 52° angles at the top
and 38° angles at thebottom.
Inside Corner Outside Corner
Left side Bevel left 33.9°
Mitre table set at right 31.62°
Save left end of cut
Bevel right 33.9°
Mitre table set at left 31.62°
Save left end of cut
Right side Bevel right 33.9°
Mitre table set at left 31.62°
Save right end of cut
Bevel left 33.9°
Mitre table set at right 31.62°
Save right end of cut
Alternative Method for Cutting Crown Moulding
Cutting crown moulding using this method does not require a bevel cut.
Minute changes in the mitre angle can be made without affecting the
bevel angle. When corners other than 90° are encountered, the saw can be
quickly and easily adjusted forthem.
Instructions for Cutting Crown Moulding Angled Between
the Fence and Base of the Saw for All Cuts (Fig. V2)
1. Angle the moulding so the bottom of the moulding (the part which
goes against the wall when installed) is against the fence
13
and the
top of the moulding is resting on the saw table
17
.
2. The angled “flats” on the back of the moulding must rest squarely on
the fence and sawtable.
Inside Corner Outside Corner
Left side Mitre right at 45°
Save right side of cut
Mitre left at 45°
Save right side of cut
Right side Mitre left at 45°
Save left side of cut
Mitre right at 45°
Save left side of cut
Special Cuts

WARNING: Never make any cut unless the material is secured
on the table and against thefence.
Aluminum Cutting (Fig. W1, W2)
ALWAYS USE THE APPROPRIATE SAW BLADE MADE ESPECIALLY FOR
CUTTINGALUMINUM.
Certain workpieces may require the use of a clamp or fixture to prevent
movement during the cut. Position the material so that you will be cutting
the thinnest cross section, as shown in FigureW1. FigureW2 illustrates the
wrong way to cut theseextrusions.
Use a stick wax cutting lubricant when cutting aluminum. Apply the stick
wax directly to the saw blade
46
before cutting. Never apply stick wax to
a moving blade. The wax provides proper lubrication and keeps chips from
adhering to theblade.
Bowed Material (Fig. X1, X2)
When cutting bowed material always position it as shown in FigureX1 and
never like that shown in FigureX2. Positioning the material incorrectly will
cause it to pinch theblade.
Cutting Plastic Pipe or Other Round Material
Plastic pipe can be easily cut with your saw. It should be cut just like
wood and CLAMPED OR HELD FIRMLY TO THE FENCE TO KEEP IT FROM
ROLLING. This is extremely important when making anglecuts.
Cutting Large Material (Fig.Y)
Occasionally you will encounter a piece of wood a little too large to fit
beneath the lower guard. If this occurs, place your right thumb on the
upper side of the guard
1
and roll the guard up just enough to clear the
workpiece, as shown in FigureY. Avoid doing this as much as possible, but
if need be, the saw will operate properly and make the bigger cut. NEVER
TIE, TAPE, OR OTHERWISE HOLD THE GUARD OPEN WHEN OPERATING
THISSAW.
