22
ENGLISH
Protecting the Environment
Separate collection. Products and batteries marked with this
symbol must not be disposed of with normal householdwaste.
Products and batteries contain materials that can be recovered or
recycled reducing the demand for raw materials. Please recycle
electrical products and batteries according to local provisions. Further
information is available at www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails to produce
sufficient power on jobs which were easily done before. At the end of its
technical life, discard it with due care for our environment:
• Run the battery pack down completely, then remove it from the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a local recycling
station. The collected battery packs will be recycled or disposed of
properly.
Quick Release Clamps: DWS5026-XJ
Dust Bag: DW7053-QZ (Fig. D)
Equipped with a zipper for easy emptying, the dust bag
40
will capture the
majority of the sawdustproduced.
Leg Stands: DE7023-XJ, DE7033-XJ (Fig. E)
The leg stand
41
is used to extend the table width of thesaw.
Clamp Brackets: DE7025-XJ (Fig. F)
The clamp brackets
42
are used for mounting the saw to astand.
SAW BLADES: ALWAYS USE 254 mm SAW BLADES WITH 25.4 mm ARBOUR
HOLES. SPEED RATING MUST BE AT LEAST 4300 RPM. Never use a smaller
diameter blade. It will not be guarded properly. Use crosscut blades only!
Do not use blades designed for ripping, combination blades or blades with
hook angles in excess of 5°.
BLADE DESCRIPTIONS
APPLICATION DIAMETER TEETH
Construction Saw Blades (thin kerf with anti-stick rim)
General Purpose 254 mm 40
Fine Crosscuts 254 mm 60
Woodworking Saw Blades (provide smooth, clean cuts)
Fine crosscuts 254 mm 80
Non-ferrous metals 254 mm 96
