ENGLISH
English (original instructions)
CORDLESS COMPACT MITRE SAW
DCS777
Congratulations!
You have chosen a
tool. Years of experience, thorough product
development and innovation make
one of the most reliable
partners for professional power toolusers.
Technical Data
DCS777
Voltage V
DC
54
Type 2
XPS Yes
Power output W 1750
Blade diameter mm 216
Blade bore mm 30
Max. blade speed min
-1
6300
Mitre (max. positions) left and right 50°
Bevel (max. positions) left 48°
Compound mitre bevel 45°
mitre 45°
Capacities
cross-cut 90° mm 60 x 270
mitre 45° mm 60 x 190
mitre 50° mm 60 x 170
bevel 45° mm 48 x 270
bevel 48° mm 45 x 270
Overall dimensions mm 460 x 560 x 430
Weight kg 15.0
Noise values and/or vibration values (triax vector sum) according to EN62841:
L
PA
(emission sound pressure level) dB(A) 90
L
WA
(sound power level) dB(A) 105
K (uncertainty for the given sound level) dB(A) 3
The vibration and/or noise emission level given in this information sheet has
been measured in accordance with a standardised test given in EN62841
and may be used to compare one tool with another. It may be used for a
preliminary assessment ofexposure.
WARNING: The declared vibration and/or noise emission level
represents the main applications of the tool. However if the tool is
used for different applications, with different accessories or poorly
maintained, the vibration and/or noise emission may differ. This may
significantly increase the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or noise should
also take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly
reduce the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from the
effects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm (relevant for vibration), organisation
of workpatterns.
EC-Declaration of Conformity
Machinery Directive
Cordless Compact Mitre Saw
DCS777
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN62841-1:2015 +AC:2015; EN62841-3-9:2015 +AC:2016
+A11:2017.
These products also comply with Directive, 2014/30/EU and 2011/65/EU.
For more information, please contact
at the following address or
refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of
.
Markus Rompel
Vice President of Engineering, PTE-Europe
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
20.09.2019
WARNING: To reduce the risk of injury, read the instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to thesesymbols.
DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which,
if not avoided, may result in propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
