9
ENGLISH
Using an extension cable
If an extension cable is required, use an approved
extension cable suitable for the power input of this
tool (see technical data). The minimum conductor
size is 1.5 mm
2
.
When using a cable reel, always unwind the cable
completely.
Assembly and adjustment
Prior to assembly and adjustment always
unplug the tool.
Fitting and removing a saw blade (fig. B)
The tool-free blade exchange system ensures quick
and easy changing of saw blades.
• Open the blade holder (7) by fully retracting the
blade latch (5).
• Insert the saw blade into the blade holder (7)
guiding the back of the blade into the groove of
the guide roller (8).
• Release the blade latch (5).
• To remove the saw blade, fully retract the blade
latch and pull the blade out of the holder.
Saw blades
Blade type Applications
Fine-toothed cutting blade for smooth straight cuts
Coarse-toothed cutting blade for fast straight cuts
Metal cutting blade for ferrous and non-
ferrous metals
Flush cutting blade* for finishing off cuts up to a
wall or edge.
* Not available in all countries.
Always select your saw blade with great
care.
Setting the bevel angle (fig. C)
The adjustable shoe (9) allows cutting of LH and RH
bevel angles up to 45°. The bevel scale has preset
positions at 0°, 15°, 30° and 45°.
• Release the shoe lever (11).
• Slide the shoe (9) toward the saw blade.
• Tilt the shoe and set the desired bevel angle
using the scale.
• Tighten the shoe lever.
Setting the pendulum stroke (fig. A)
The adjustable pendulum stroke guarantees a
perfect cutting stroke for different materials.
• Slide the selector (10) to the desired position
referring to the table below. The selector can be
manipulated during operation.
Pos. Wood Metal Plastics
3 Fast cuts - PVC
2 Thick workpieces - Fibreglass
Acrylic
1 Plywood Aluminium -
Chipboard Non-ferrous -
0 Thin workpieces Sheet metal -
Fine cuts
Electrical safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your D
EWALT tool is double insulated in
accordance with EN 60745; therefore no
earth wire is required.
Setting the sawdust blower (fig. A)
The sawdust blower conducts an adjustable stream
of air to the saw blade to keep the workpiece clear
of sawdust during operation.
• Set the sawdust blower using the lever (4).
- Low For working with metals, when
using coolants and lubricants
and for use with dust extraction.
- Intermediate For working with wood and
similar materials in low speed.
- High For working with wood and
similar materials in high speed.
Mounting the plastic anti-scratch shoe cover
(fig. D)
The anti-scratch shoe cover (12) reduces damage to
the surface of (sensitive) workpieces.
• Click the cover onto the shoe as shown.
