DeWalt DW615 Original Instructions

ROUTER
DW614, DW615
Congratulations!
You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical data
DW614 DW615
Voltage V 230 230
UK & Ireland V 230/115 230/115
Type 4 4/5
Power input W 750 900
Power output W 500 590
No-load speed min
-1
24,000 8,000-24,000
Router carriage 2 columns 2 columns
Plunge mm 35 35
Revolver depth stop kg 3-step, 3-step,
with with
graduation graduation
Collet size 8 mm 8 mm
(GB: 1/4") (GB: 1/4")
Cutters diameter, max. mm 30 30
Weight kg 2.8 2.9
L
PA
(sound pressure) dB(A) 82 83
K
PA
(sound pressure
uncertainty) dB(A) 3 3
L
WA
(sound power) dB(A) 92 92
K
WA
(sound power
uncertainty) dB(A) 3.2 3.2
Vibration total values (triax vector sum) determined
according to EN 60745:
Vibration emission value a
h
a
h
= m/s² 5.3 7.8
Uncertainty K = m/s² 1.5 1.7
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN 60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.
WARNING: The declared vibration
emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase the
exposure level over the total working
period.
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
working period.
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
U.K. & Ireland 115 V tools 16 Amperes, in plugs
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
ENGLISH
21

DeWalt DW615 Specifications

General

Input power	900 W
Output power	590 W
Power source	AC
Routing stroke	55 mm
Collet capacity	6, 8 (5/16\
Vibration level	7.8 m/s²
Idle speed (max)	24000 RPM
Idle speed (min)	8000 RPM
Product color	Yellow

Weight and Dimensions

Weight	2900 g
