TABLE TOP MITRE SAW DW711
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough product
development and innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical data
DW711
Voltage V 230
(U.K. & Ireland only) V 230/115
Power input W 1,300/1,100
Power output W 900/800
Blade diameter mm 260
Blade bore mm 30
Max. blade speed min
-1
2,750/2,850
Max. cross-cut capacity at 90° mm 140
Max. cross-cut capacity 45° mm 100
Max. depth of cut 90° mm 90
Max. depth of bevel cut 45° mm 45
Mitre (max. positions) left 50°
right 50°
Bevel (max. positions) left 48°
Compound cuts
90° mitre
Max. depth of cut at 45° bevel mm 48
Max. depth of cut at 48° bevel mm 45
45° mitre
Max. depth of cut at 45° bevel mm 48
Max. depth of cut at 48° bevel mm 45
48° mitre
Max. depth of cut at 45° bevel mm 48
Max. depth of cut at 48° bevel mm 45
Max. ripping capacity left/right mm 180/60
Max. depth of cut bench saw mm 0 - 50
Automatic blade brake time s < 10.0
Weight kg 20
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the
tool in case of non-observance of the instructions in this
manual.
Denotes risk of electric shock.
Sharp edges.
EC-Declaration of conformity
DW711
DEWALT declares that these Power Tools have been designed in
compliance with: 98/37/EEC, 89/336/EEC, 73/23/EEC, EN 61029-1,
prEN 61029-2-11, EN 55014, EN 55014-2, EN 61000-3-2 &
EN 61000-3-3.
For more information, please contact DEWALT at the address below or
refer to the back of the manual.
Level of sound pressure according to 86/188/EEC & 98/37/EEC,
measured according toprEN 61029-2-11:
DW711
L
pA
(sound pressure) dB(A)* 90.8
L
WA
(acoustic power) dB(A) 98.8
* at the operator’s ear
Take appropriate measures for the protection of hearing.
Weighted root mean square acceleration value according to
prEN 61029-2-11:
DW711
< 2.5 m/s
2
TÜV Rheinland
Product and Safety GmbH (TRPS)
Am Grauen Stein 1
D-51105 Köln
Germany
Cert. No.
BM 9910407
Director Engineering and Product Development
Horst Großmann
DEWALT, Richard-Klinger-Straße 11
D-65510, Idstein, Germany
B&D_19a

DeWalt DW711 Specifications

General

Input power	1300 W
Power source	AC
Blade diameter	260 mm
Idle speed (max)	2750 RPM
Sound pressure level	103 dB

Weight and Dimensions

Depth	490 mm
Width	590 mm
Height	620 mm
Weight	20000 g
