12
MITRE SAW DW714
Congratulations!
You have chosen a
tool. Years of experience, thorough
product development and innovation make D
WALT one of the most
reliable partners for professional power tool users.
Technical Data
DW714 B5, IN DW714 ZA
Voltage V
AC
220–240 230
Type 1 1
Frequency Hz 50/60 50
Power input W 1650 1650
Blade diameter mm 254 254
Bore diameter mm 30 (B5) 30
25.4 (IN)
Blade thickness mm 3.2 3.2
Max. blade speed min
-1
4600 4600
Max. cross-cut capacity 90° mm 130 130
Max. mitre capacity 45° mm 91 91
Max. depth of cut 90° mm 89 89
Max. depth of bevel cross-cut 45°mm 50 50
Mitre (max. positions) left 47° 47°
right 52° 52°
Bevel (max. positions) left 45° 45°
right 0° 0°
0° mitre, 0° bevel
Resulting width at max. height 89 mm mm 95
Resulting height at max. width 130 mm mm 68
45° mitre, 0° bevel
Resulting width at max. height 89 mm mm 67
Resulting height at max. width 91 mm mm 68
0° mitre, 45° bevel
Resulting width at max. height 50 mm mm 95
Resulting height at max. width 130 mm mm 40
45° mitre, 45° bevel
Resulting width at max. height 45 mm mm 70
Resulting height at max. width 91 mm mm 40
Automatic blade brake time s < 10.0
Weight kg 13.1
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal
injury which, if not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
Safety Instructions
WARNING! When using electric tools basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and personal injury
including the following.
Read all these instructions before attempting to operate this product
and save these instructions.
SAVE THIS MANUAL FOR FUTURE REFERENCE
General Safety Rules
1. Keep work area clear.
Cluttered areas and benches invite injuries.
2. Consider work area environment.
Do not expose the tool to rain. Do not use the tool in damp or wet
conditions. Keep the work area well lit (250–300 Lux). Do not use
the tool where there is a risk of causing fire or explosion, e.g., in the
presence of flammable liquids and gases.
3. Guard against electric shock.
Avoid body contact with earthed surfaces (e.g., pipes, radiators,
cookers and refrigerators). When using the tool under extreme
conditions (e.g., high humidity, when metal swarf is being
produced, etc.), electric safety can be improved by inserting an
isolating transformer or a (FI) earth-leakage circuit-breaker.
4. Keep other persons away.
Do not let persons, especially children, not involved in the work,
touch the tool or the extension cord and keep them away from the
work area.
5. Store idle tools.
When not in use, tools must be stored in a dry place and locked up
securely, out of reach of children.
6. Do not force the tool.
It will do the job better and safer at the rate to which it was
intended.
7. Use the right tool.
Do not force small tools to do the job of a heavy duty tool. Do
not use tools for purposes not intended; for example do not use
circular saws to cut tree limbs or logs.
8. Dress properly.
Do not wear loose clothing or jewellery, as these can be caught in
moving parts. Non-skid footwear is recommended when working
outdoors. Wear protective hair covering to contain long hair.
9. Use protective equipment.
Always use safety glasses. Use a face or dust mask if working
operations create dust or flying particles. If these particles might
be considerably hot, also wear a heat-resistant apron. Wear ear
protection at all times. Wear a safety helmet at all times.
10. Connect dust extraction equipment.
If devices are provided for the connection of dust extraction and
collecting equipment, ensure these are connected and properly
used.
11. Do not abuse the cord.
Never yank the cord to disconnect it from the socket. Keep the
cord away from heat, oil and sharp edges. Never carry the tool by
its cord.
12. Secure work.
Where possible use clamps or a vice to hold the work. It is safer
than using your hand and it frees both hands to operate the tool.
13. Do not overreach.
Keep proper footing and balance at all times.
14. Maintain tools with care.
Keep cutting tools sharp and clean for better and safer
performance. Follow instructions for lubricating and changing
accessories. Inspect tools periodically and if damaged have
them repaired by an authorized service facility. Keep handles and
switches dry, clean and free from oil and grease.
15. Disconnect tools.
When not in use, before servicing and when changing accessories
such as blades, bits and cutters, disconnect tools from the power
supply.
16. Remove adjusting keys and wrenches.
Form the habit of checking to see that adjusting keys and
wrenches are removed from the tool before operating the tool.
To Next Page
