DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.
Attaching Side Handle (Fig. B)
WARNING: Before using the tool, check that the handle is
tightenedsecurely.
WARNING: The side handle should always be used to
maintain control of the tool at alltimes.
Screw the side handle
4
tightly into one of the holes
6
on
either side of the gearcase.
Mounting and Removing the Guard (Fig. C)
CAUTION: Guards must be used with thisgrinder.
To Mount the Guard
1. Place the angle grinder on a table, spindleup.
2. Press the guard
3
down (Fig. C1).
3. Position the guard between your body and workpiece.
4. Tight the screw
12
holding the cinch collar firmly around
the neck of spindle (Fig. C2)
To Remove the Guard
1. Loosen the screw
12
holding the cinch collar around the
neck of thespindle.
2. Lift up on theguard.
Fitting and Removing a Grinding Disc
(Fig. A, D, E)
WARNING: Do not use a damageddisc.
1. Place the tool on a table, guardup.
2. Fit the backing flange
7
correctly onto the spindle
8
(Fig.D).
3. Place the disc
9
on the flange
7
. When fitting a disc with a
raised centre, make sure that the raised centre
10
is facing
the flange
7
.
4. Screw the outer flange
11
onto the spindle
8
(Fig.E). The
ring on the flange
11
must face towards the disc when
fitting a grindingdisc.
5. Press the spindle lock button
2
and rotate the spindle
8
until it locks inposition.
6. Tighten the flange
11
with the providedspanner.
7. Release the spindlelock.
8. To remove the disc, loosen the flange
11
with the
provided spanner.
Prior to Operation
• Install the guard and appropriate disc or wheel. Do not use
excessively worn discs orwheels.
• Be sure the inner and outer flange are mountedcorrectly.
• Make sure the disc or wheel rotates in the direction of the
arrows on the accessory and thetool.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.
WARNING:
• Ensure all materials to be ground or cut are secured
inplace.
• Apply only a gentle pressure to the tool. Do not exert
side pressure on thedisc.
• Avoid overloading. Should the tool become hot, let it
run a few minutes under no loadcondition.
Proper Hand Position (Fig. A, F)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side handle
4
,
with the other hand on the body of the tool, as shown in
FigureF.
Switches
WARNING: Do not switch the tool on or off when
underload.
WARNING: Before using the tool, check that the handle is
tightenedsecurely.
Slider Switch (Fig. A)
DW802/DWE4010/DWE4114/DWE4115
To start the tool, slide the on/off slider switch
1
toward
the front of the tool. To stop the tool, release the on/off
sliderswitch.
For continuous operation, slide the switch toward the front of
the tool and press the forward part of the switchinward.
To stop the tool while operating in continuous mode, press the
rear part of the slider switch andrelease.
