8
ENGLISH
Keyless Chuck (Fig. F–H)
DWD024S, DWD025
The DWD024S, DWD025 features a keyless chuck
4
for greater
convenience. To insert a drill bit or other accessory, follow the
steps listedbelow.
1. Grasp the rear half of the chuck with one hand and use
your other hand to rotate the front half counterclockwise,
as shown in FigureD. Rotate far enough so that the chuck
opens sufficiently to accept the desiredaccessory.
2. Insert the bit or other accessory about 19 mm into the chuck
and tighten securely by holding the rear half of the chuck
and rotating the front portion in the clockwise direction.
When the chuck is nearly tightened, you will hear a clicking
sound. After 4–6 clicks, the chuck is securely tightened
around theaccessory.
3. To release the accessory, repeat step 1listedabove.
WARNING: Do not attempt to tighten drill bits (or any
other accessory) by gripping the front part of the chuck
and turning the tool on. Damage to the chuck and
personal injury mayresult.
Keyed Chuck (Fig. A, D, E)
DWD024
The DWD024 features a keyed chuck
4
. To insert a drill bit or
other accessory, follow the steps listedbelow.
1. Open the chuck jaws by turning collar by hand and insert
the shank of the bit about 19 mm into chuck. Tighten the
chuck collar byhand.
2. Place chuck key in each of the three holes, and tighten in
clockwise direction. It’s important to tighten chuck with all
threeholes.
To release the bit, turn the chuck counterclockwise in just one
hole, then loosen the chuck byhand.
Removal of Keyed Chuck (Fig.D)
Tighten the chuck around the shorter end of a hex key (not
supplied) of 6 mm or greater size. Using a soft hammer, strike
the key sharply in the counterclockwise direction when viewed
from the front of the tool. This will loosen the chuck so that it
can be removed byhand.
Keyed Chuck Installation (Fig.E)
Screw the chuck on by hand as far as it will go. Insert the shorter
end of a hex key (not supplied) of 6 mm or greater size and
strike it in the clockwise direction with a softhammer.
Setting the Drilling Depth (Fig. C)
1. Insert the required drill bit into thechuck.
2. Loosen the side handle
7
.
3. Fit the depth adjustment rod
8
through the hole in the side
handleclamp.
4. Adjust the drilling depth asshown.
5. Tighten the sidehandle.
Hammer-only mode
Use hammer‑only mode for simultaneous rotating
and impacting for masonry, brick andconcrete.
Mode Selector (Fig. A, B)
NOTICE: Tool must come to a complete stop before
activating the mode selector button or damage to the tool
mayresult.
Select the required operating mode by sliding the mode
selector
9
to the correspondingsymbol.
Drill-Only mode
Use drill‑only mode for wood, metal, andplastics.
Forward/Reverse Lever (Fig. A)
The forward/reverse lever
3
is used for withdrawing bits
from tight holes and removing screws. It is located above the
triggerswitch.
To reverse the motor, release the trigger switch FIRST and then
push the lever to the right (viewed when holding the drill in the
operatingposition).
After any reversing operations, return lever to forwardposition.
Side Handle (Fig. A)
WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximizecontrol.
A side handle comes included with the DWD024, DWD024S,
DWD024S‑XE and the DWD025S‑XE. The side handle
7
can be
fitted to suit both right‑hand and left‑handusers.
To Adjust the Side Handle
1. Loosen the side handle
7
by turning itcounterclockwise.
2. Rotate the side handle to the desiredposition.
3. Tighten the side handle by turning itclockwise.
To Change Sides
For right-hand users: Slide the side handle clamp over the
chuck, handle at theleft.
For left-hand users: Slide the side handle clamp over the
chuck, handle at theright.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
