Date Code Position (Fig.A)
The production date code
11
consists of a 4‑digit year followed
by a 2‑digit week and is extended by a 2‑digit factorycode.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Variable speed trigger switch
2
Lock‑on button
3
Forward/reverse lever
4
Chuck
5
Cord protector with key holder
6
Cord set
7
Side handle
8
Depth adjustment rod
9
Mode selector
10
Main handle
11
Date code position
Intended Use
These heavy‑duty variable speed percssion drills are designed
for professionaldrilling.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy‑duty percussion drills are professional powertools.
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
g
Wear earprotection.
f
Wear eyeprotection.
Package Contents
The package contains:
1 Drill
1 Chuck key (DWD024)
1 Depth rod
1 Side handle
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5 mm
2
; the
maximum length is 30 m.
When using a cable reel, always unwind the cablecompletely.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.
Your DeWALT tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
This product is intended to be used with a safety transformer
manufactured to BSEN61558 and BS4343. Never work without
this transformer inplace.
If the supply cord is damaged, it must be replaced only by
DeWALT or an authorised serviceorganisation.
Mains Plug Replacement
(U.K.& Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead t o the live terminal in theplug.
• Connect the blue lead to the neutralterminal.

WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Residual Risks
The following risks are inherent to the use of drills:
• Injuries caused by touching the rotating parts or hot parts of
thetool.
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of squeezing fingers when changingaccessories.
• Health hazards caused by breathing dust developed when
working inwood.
• Risk of personal injury due to flyingparticles.
• Risk of personal injury due to prolongeduse.
Safety Instructions When Using Long Drill Bits
• Never operate at higher speed than the maximum
speed rating of the drill bit. At higher speeds, the bit is likely
to bend if allowed to rotate freely without contacting the
workpiece, resulting in personalinjury.
• Always start drilling at low speed and with the bit tip
in contact with the workpiece. At higher speeds, the bit is
likely to bend if allowed to rotate freely without contacting the
workpiece, resulting in personalinjury.
• Apply pressure only in direct line with the bit and do not
apply excessive pressure. Bits can bend causing breakage or
loss of control, resulting in personalinjury.

WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.

DeWalt DWD024 Specifications

General

Chuck type	Key
Adjustable speed	Yes
Idle speed (max)	2800 RPM
Impact rate (high speed)	47600 bpm
Drilling diameter in wood (max)	25 mm
Drilling diameter in steel (max)	10 mm
Drilling diameter in concrete (max)	16 mm
Input power	650 W
Power source	AC
Product color	Black, Silver, Yellow

Weight and Dimensions

Weight	16500 g
