DeWalt DWE4369-QS User Manual

8
ENGLISH
Wear eyeprotection.
Electronic Brake
Date Code Position (Fig. D)
The date code
11
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2018 XX XX
Year of Manufacture
Description (Fig. A, B)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Spindle lock button
2
Spindle
3
Side handle
4
Backing flange
5
Clamp nut
6
Guard
7
Slider switch
8
Variable speed dial (DWE4357, DWE4369)
9
Guard release lever
10
LED Indicator
Intended Use
Your heavy-duty small angle grinder has been designed
for professional grinding, sanding, wire brushing and
cuttingapplications.
DO NOT use grinding wheels other than centre depressed
wheels and flapdiscs.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your heavy-duty angle grinder is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Features
Anti-vibration Side Handle
DWE4369
The anti-vibration side handle offers added comfort by
absorbing the vibrations caused by thetool.
No-Volt
The No-volt function stops the grinder restarting without the
switch being cycled if there is a break in the powersupply.
E-Clutch
This unit is equipped with an E-Clutch (Electronic Clutch), which
in the event of a stall or wheel pinch, the unit will be shut off to
reduce the reaction torque to the user. The switch needs to be
cycled (turned on and off) to restarttool.
Brake
When the slider switch is released the motor immediately turns
off and electronically brakes stopping the accessoryquickly.
Kickback Brake™
When a severe pinch, stall, or bind-up event is sensed the
electronic brake engages with maximum force to quickly stop
the wheel, reduce the movement of the grinder, and shut the
grinder off. The switch needs to be cycled (turned off and then
on) to restarttool.
Constant Clutch™
When overloaded or stalled the motor torque is reduced. If load
is reduced the torque and RPM will increase. If the tool is stalled
for an extended amount of time it will shut-off and require the
switch to cycle torestart.
Electronic Soft Start
This feature limits the initial start up momentum, allowing the
speed to build up gradually over a 1 secondperiod.
LED Indicator (Fig. A)
The LED indicator
10
will remain lit green during normal
activity, or blink in a pattern of red light to alert you a tool
protection feature has been activated. Refer to the LED Guide at
the back of this manual for explanations of blinkpatterns.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
Attaching Side Handle (Fig. B)

WARNING: Before using the tool, check that the handle is
tightenedsecurely.
Screw the side handle
3
tightly into one of the holes on either
side of the gear case. The side handle should always be used to
maintain control of the tool at alltimes.
Guards

CAUTION: Guards must be used with all grinding
wheels, cutting wheels, sanding flap discs, wire
brushes, and wire wheels. Refer to Figure A to see
guards provided with the unit. Some applications may
require purchasing the correct guard from your local
dealer or authorized servicecentre.

DeWalt DWE4369-QS Specifications

General

Brand	DeWalt
Model	DWE4369-QS
Category	Grinder
Language	English
