DeWalt DWMT70784 - Cut-Off Tool Specifications; Specifications

2
English
A. Wheel Guard
B. Hex Head Screw
C. Washer
D. Cutting Wheel
E. Collet
SPECIFICATIONS
MODEL
DWMT70784
FREE SPEED (@90PSI)
19000 RPM
EXHAUST TYPE
Rear
WHEEL DIAMETER
3" (76.2MM)
WHEEL ARBOR HOLE
3/8" (10MM)
SPINDLE SCREW
M6 x 12MM Hex
AVERAGE AIR CONSUMPTION
(@90PSI)
31 SCFM (14.6 L/s)
4.4 CFM (2.1 L/s)
NET WEIGHT
1.8 LBS (0.82Kg.)
AIR INLET SIZE
1/4" NPT(F)
RECOMMENDED HOSE SIZE
3/8" (10MM)
MAX. AIR PRESSURE
90 PSI
DWMT70784 CUT-OFF TOOL
F. Spindle
G. ¼" Air Inlet
H. Exhaust
I. Trigger
J. Safety Throttle Lever
K. Ergonomic Body
FIG.1
A
B
C
D
E
F
K
J
I
G
H
G
