ENGLISH
6

Denotes risk of electricshock.

Denotes risk offire.
Denotes sharpedges.
EC-Declaration of Conformity
Machinery Directive
Cross-cut Mitre Saw
DWS771, DWS777
DeWALT
declares that these products described under Technical Data are in compliance with:
2006/42/EC, EN61029-1:2009 + A11:2010, EN61029-2-9:2012 + A11:2013.
These products also comply with Directive 2004/108/EC (until 19.04.2016), 2014/30/EU (from
20.04.2016) and 2011/65/EU. For more information, please contact
DeWALT
at the following
address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and makes this declaration
on behalf of
DeWALT
.
Markus Rompel
Director Engineering
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
26.02.2016
Safety Instructions
WARNING! When using electric tools basic safety precautions should always be followed
to reduce the risk of fire, electric shock and personal injury including thefollowing.
Read all these instructions before attempting to operate this product and save theseinstructions.
SAVE THIS MANUAL FOR FUTURE REFERENCE
General Safety Rules
1 . Keep work areaclear.
Cluttered areas and benches inviteinjuries.
2 . Consider work areaenvironment.
Do not expose the tool to rain. Do not use the tool in damp or wet conditions. Keep the
work area well lit (250–300 Lux). Do not use the tool where there is a risk of causing fire or
explosion, e.g., in the presence of flammable liquids andgases. Work area should be well
ventilated.
3 . Guard against electricshock.
Avoid body contact with earthed surfaces (e.g., pipes, radiators, cookers and refrigerators).
When using the tool under extreme conditions (e.g., high humidity, when metal swarf is being
produced, etc.), electric safety can be improved by inserting an isolating transformer or a (FI)
earth-leakage circuit-breaker.
4 . Keep other personsaway.
Do not let persons, especially children, not involved in the work, touch the tool or the
extension cord and keep them away from
the workarea.
5 . Store idletools.
When not in use, tools must be stored in a dry place and locked
up securely, out of reach ofchildren.
6 . Do not force thetool.
It will do the job better and safer at the rate to which it wasintended.
7 . Use the righttool.
Do not force small tools to do the job of a heavy duty tool. Do not use tools for purposes not
intended; for example do not use circular saws to cut tree limbs orlogs.
8 . Dressproperly.
Do not wear loose clothing or jewellery, as these can be caught in moving parts. Non-skid
footwear is recommended when working outdoors. Wear protective hair covering to contain
longhair.
9 . Use protectiveequipment.
Always use safety glasses. Use a face or dust mask if working operations create dust or flying
particles. If these particles might be considerably hot, also wear a heat-resistant apron. Wear
ear protection at all times. Wear a safety helmet at alltimes.
10 . Connect dust extractionequipment.
If devices are provided for the connection of dust extraction and collecting equipment, ensure
these are connected and properlyused.
11 . Do not abuse thecord.
Never yank the cord to disconnect it from the socket. Keep the cord away from heat, oil
and sharp edges. Never carry the tool by itscord.
12 . Securework.
Where possible use clamps or a vice to hold the work. It is safer than using your hand and it
frees both hands to operate thetool.
CROSS-CUT MITRE SAW
DWS771, DWS777
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product development and
innovation make
DeWALT
one of the most reliable partners for professional power toolusers.
Technical Data
DWS771 DWS777
Voltage V 230 230
(U.K. & Ireland only) V 230 230/115
Type 1 1
XPS Yes Yes
Power input W 1550 1800/1600
Blade diameter mm 216 216
Blade bore mm 30 30
Max. blade speed min
-1
2600–5200 6300
Mitre (max. positions) left and right 50° 50°
Bevel (max. positions) left 48° 48°
Compound mitre bevel 45° 45°
mitre 45° 45°
Capacities
cross-cut 90° mm 60 x 270 60 x 270
mitre 45° mm 60 x 190 60 x 190
mitre 48° mm 60 x 180 60 x 180
bevel 45° mm 48 x 270 48 x 270
bevel 48° mm 45 x 270 45 x 270
Overall dimensions mm 460 x 560 x 430 460 x 560 x 430
Weight kg 15.0 15.0
Noise values and vibration values (triax vector sum) according to EN61029:
L
PA
(sound pressure) dB(A) 91 93
L
WA
(acoustic power) dB(A) 102 104
K (acoustic power uncertainty) dB(A) 3.2 3.9
Vibration emission value ah
a
h
= m/s² 2.1 2.1
Uncertainty K = m/s² 1.5 1.5
The vibration emission level given in this information sheet has been measured in accordance
with a standardised test given in EN61029 and may be used to compare one tool with another.
It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level represents the main applications of the
tool. However if the tool is used for different applications, with different accessories or
poorly maintained, the vibration emission may differ. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration should also take into account the times
when the tool is switched off or when it is running but not actually doing the job. This
may significantly reduce the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from the effects of vibration
such as: maintain the tool and the accessories, keep the hands warm, organisation of
workpatterns.
Fuses
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
U.K. & Ireland 115 V tools 16 Amperes, mains
NOTE: This device is intended for the connection to a power supply system with maximum
permissible system impedance Zmax of 0.28 Ohm at the interface point (power service box) of
user’ssupply.
The user has to ensure that this device is connected only to a power system which fulfils the
requirement above. If necessary, the user can ask the public power supply company for the
system impedance at the interfacepoint.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please read the
manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result
in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result
in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in propertydamage.
English (original instructions)
