DeWalt DWS780LST Original Instructions

38
ENGLISH
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal injury, turn
tool off and disconnect tool from power source before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.
Unpacking (Fig. A1,F)
1. Open the box and lift the saw out by the con venient carrying handle
3
,
as shown in FigureF.
2. Place the saw on a smooth, flatsurface.
3. Release the rail lock knob
6
, and push the saw head back to lock it in
the rearposition.
4. Press down lightly on the operating handle
2
and pull out the lock
down pin
11
.
5. Gently release the downward pressure and hold the operating handle,
allowing it to rise to its fullheight.
Bench Mounting (Fig. A1)
Holes
18
are provided in all four feet to facilitate bench mounting. Two
different-sized holes are provided to accommodate different sizes of screws.
Use either hole; it is not necessary to useboth.
Always mount your saw firmly to a stable surface to prevent movement.
To enhance the tool’s portability, it can be mounted to a piece of 12.7 mm
or thicker plywood which can then be clamped to your work support or
moved to other job sites andreclamped.
NOTE: If you elect to mount your saw to a piece of plywood, make sure that
the mounting screws don’t protrude from the bottom of the wood. The
plywood must sit flush on the work support. When clamping the saw to
any work surface, clamp only on the clamping bosses where the mounting
screw holes are located. Clamping at any other point will interfere with the
proper operation of thesaw.

CAUTION: To prevent binding and inaccuracy, be sure the mounting
surface is not warped or otherwise uneven. If the saw rocks on the
surface, place a thin piece of material under one saw foot until the saw
sits firmly on the mountingsurface.
Assembling the Base Extensions (Fig. Y)

WARNING: Base extensions must be assembled to both sides of
the saw's base before using thesaw.

WARNING: Be sure to adjust the base extensions using the
mounting slots so they are level with the saw'sbase.
1. Locate the holes above the hand indentations
16
on the side of
thebase.
2. Using the supplied wrench or a T30 wrench, attach the screw
60
through the washer
61
, through the base extension
15
, and into the
holes on thebase.
3. Ensure the extension is secure by pulling on the extension to verify
nomovement.
4. Repeat steps 1 through 3 on the otherside.
Changing or Installing a New Saw Blade
Removing the Blade (Fig. G1–G4)

WARNING: To reduce the risk of injury, wear gloves when handling
the sawblade.

WARNING: To reduce the risk of injury, turn unit off and
disconnect machine from power source before installing and
Description (Fig. A1–E)

WARNING: Never modify the power tool or any part of it. Damage or
personal injury couldresult.
Fig. A1
1
Lower guard
2
Operating handle
3
Carrying handle
4
Kerf plate
5
Mitre latch button
6
Rail lock knob
7
Rail set screw adjustment
8
Date code
9
Rails
10
Bevel scale
11
Lock down pin
12
Fence adjustment knob
13
Sliding ence
14
Base fence
15
Base extension/carry handle
16
Hand indentation
17
Table
18
Bench mounting holes
19
Mitre scale
20
Dust duct inlet
21
Mitre lock handle
Fig. A2
22
Trigger switch
23
Lock-off lever
24
Padlock hole
25
XPS™ on/off switch
26
Wing nut
27
Depth adjustment screw
28
Grooving stop
29
Blade wrench
30
Base
31
Bevel lock knob
32
0° bevel stop
33
Right-hand flip down stop
34
Dust port
35
Belt cover
36
Mitre detent override
Optional accessories
Fig. B
37
DWS5026-XJ Workpiece clamp
Fig. C
38
DW7053-QZ Dustbag
Fig. D
39
DE7023-XJ / DE7033-XJ Leg
stand
Fig. E
40
DE7025-XJ Clamp brackets
Intended Use
Your
DeWALT
DWS727 mitre saw has been designed for professional
cutting of wood, wood products and plastics. When using the appropriate
saw blades, sawing aluminium is also possible. It performs the sawing
operations of cross-cutting, bevelling and mitring easily, accurately
andsafely.
DO NOT use under wet conditions or in the presence of flammable liquids
orgases.
This mitre saw is a professional powertool.
DO NOT let children come into contact with the tool. Supervision is
required when inexperienced operators use thistool.
Date Code Position (Fig. A)
The date code
8
, which also includes the year of manufacture, is printed
into thehousing.
Example:
2019 XX XX
Year of Manufacture
Wear earprotection.
Wear eyeprotection.
Keep hands away fromblade.
Visible radiation. Do not stare intolight.
• Young children and the infirm. This appliance is not intended for use
by young children or infirm persons withoutsupervision.
• This product is not intended for use by persons (including children)
suffering from diminished physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are supervised by a person
responsible for their safety. Children should never be left alone with
thisproduct.
