WARNING: Before attempting to attach DeWALT
power tool holster to metal studs and drywall
consult your local authority having jurisdiction
“AHJ” for proper fastening requirements.
Improper installation can cause personal injury and or
propertydamage.
DeWALT Metal Rail Mounting (Fig. B—D)
1. Slide the power tool shelf
2
over the power tool
holster
1
engaging the lances
3
into the lance slots
4
in the power tool shelf
2
.
NOTE: Ensure that all six lances
3
are completely seated
in the lance slots
4
.
2. Secure the shelf assembly
18
to the metal rail mounting
bracket
15
using four 1/4-20 x .0750 socket head screw
11
, four washers
14
and four nuts
13
as shown in Fig. C.
Torque the hardware to 15in/lbs.
3. After assembly is complete place top mat
16
in the
power tool shelf
2
.
4. Remove the paper backing from the two spacer
blocks
17
. Install the two spacer blocks
17
with the
sticky side to the back of thecabinet
5
.
NOTE: Spacer blocks
17
should be located on the lower
corners of the cabinet, approximately 1" (25mm) from
theedges.
5. Mount the shelf assembly to a DeWALT metal rail
so the metal rail mounting bracket
15
engages as
shown in Fig. D.
Wall Mounting (Fig. B, E)
1. Slide the power tool shelf
2
over the power tool
holster
1
engaging the lances
3
into the lance slots
4
in the power tool shelf
2
.
NOTE: Ensure that all six lances
3
are completely seated
in the lance slots
4
.
2. Locate and mark wall studs
19
if installing over drywall.
3. Drill two 1/8" pilot holes.
NOTE: Use outside screw holes
20
for mounting to studs
24" (609 mm) on center. Use inside screw holes
21
for
mounting to studs 16" (406 mm) on center.
4. Position the DWST82822 shelf assembly
18
onto the
wall and straighten it using a level.
5. Place a washer
14
on each #14x 3” screw
10
and insert
the screws through the screw holes
20
as shown in Fig. E.
6. Drive the #14x 3” screws
10
through the screw holes
20
and into the wall studs
19
until snug.
7. After assembly is complete place top mat
16
in the
power tool shelf
2
.
Masonry/Concrete Walls
Prior to installing DWST82822 shelf assembly
18
shelf
assembly
18
on a masonry or concrete wall, waterproof the
surface to preventmoisture.
DO NOT attempt to install the DWST82822 shelf
assembly
18
using any type of masonry nail. Use #10 or
4.8mm pan or washer head masonry screws (not included).
1. Slide the power tool shelf
2
over the power tool
holster
1
engaging the lances
3
into the lance slots
4
in the power tool shelf
2
.
DWST82822 Assembly and Installation
(Fig.A—E)

WARNING: Failure to comply with installation
may result in personal injury, product or
property damage.
Required Tools and Hardware
You will need to gather a few common tools and hardware.
Always consult your local building code for proper hardware.
DeWALT METAL RAIL MOUNTING INSTALLATION
• Safety glasses
• Gloves
• Screwdriver
• 3/8" (10mm) wrench
• 7/16" (11mm) wrench
• 5/32" (4mm) hex wrench
• Washers
14
• 1/4-20 x .0750 Socket head screws
11
• Nuts
13
• Spacer blocks
17
OPTIONAL WALL MOUNTING INSTALLATION
• Safety glasses
• Gloves
• 3/8" (10mm) wrench
• #14x 3” screws
10
• Washers
14
‑ Use masonry screws (not supplied) for mounting to
masonry block or a concrete wall.
‑ Use the included #14x 3” screws
10
for mounting to
woodstuds.

CAUTION: Always use the correct screws for the
surface that DeWALT power tool holster will be
anchored in. Using the wrong screw will reduce the
holding force required for proper installation possibly
resulting in personal injury or property damage.
Decide how you would like to install your DWST82822 power
tool holster
1
before you begin.
1. DWST82822 power tool holster
1
can be installed on a
wood framed, masonry, or concrete wall. See Installing
onto Wall Mounting, or Masonry/Concrete Walls to
install on those surfaces.
NOTE: The DWST82822 power tool holster
1
may also
be installed over drywall and metal studs.
WeightCapacity

CAUTION: To reduce the risk of injury, do not
overload the
DeWALT power tool holster shelf
andcabinet .
Do not hang more than 100lbs (45kg) on each
DWST82822
Do not hang more than 200lbs (90kg) on each DWST82824
when installed on
DeWALT metal rail.
Do not hang more than 500lbs (227kg) on each
DWST82824
when installed directly to wall studs, concrete or masonry.
