DWX723/DWX724 Miter Saw Stands
B
2
1
K
A
C
D
E
F
G
H
I
J
FIG. 1
12
DWX723 69.5"(1765.3 mm) 151" (3835.4 mm)
DWX724 43" (1092.2 mm) 100" (2540 mm)
Components List
A. Beam
B. DW7231 Miter saw mounting brackets
C. Extension arm
D. DW7232 Work piece support and length
stop
E. Extension arm end cap
F. Extension arm lock lever
G. Release levers
H. Carry handle
I. Locking locator clip
J. Leg lock lever
K. Release button
