DeWalt DXCM20020US - Page 3

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
1
On/off switch
2
Air tank pressure gauge
3
Regulated pressure gauge
4
Pressure regulator knob
5
Quick couplers
6
Safety valve
7
Air tank drain valve
8
Air tank
9
Handle
10
Power cord wrap
11
Air intake filter
12
Wheel
13
Rubber foot
14
Electric motor & air
compressor pump
1
3
8
14
10
11
2
9
6
12
7
13
Fig. A
4
5
