DeWalt DXPW3200V - MAINTENANCE; Nozzle Cleaning; Water Inlet Filter Cleaning; STORAGE

10
ENGLISH
MAINTENANCE

WARNING: Risk of burn hazard. When performing
maintenance, you may be exposed to hot surfaces,
water pressure or moving parts that can cause
serious injury ordeath.

WARNING: Risk of fire hazard. Always disconnect,
spark plug wire, let the engine cool and release all
water pressure before performing any maintenance
or repair. The engine contains flammable fuel.
Do not smoke or work near open flames while
performingmaintenance.
To ensure efficient operation and longer life of your pressure
washer, a routine maintenance schedule should be prepared
and followed. If the pressure washer is used in unusual
conditions, such as high-temperatures or dusty conditions, more
fre quent maintenance checks will berequired.
Engine
Consult the Engine Owner’s Manual for the man u fac tur er's
recommendations for any and all maintenance. NOTE: The
engine drain plug is located at the rear of theunit.
Pump
The pump was filled with oil at the factory. The pump on
this unit is maintenance free and requires no oil to be added
or changed. If there is a problem with the pump contact us
at AUST 1800 841 749/ NZ0800467813 or reference the
TroubleshootingGuide.
Connections
Connections on pressure washer hoses, gun and spray wand
should be cleaned regularly and lubricated with light oil or
lithium grease to prevent leakage and damage to the o-rings.
Nozzle Cleaning (Fig. L)
If the nozzle becomes clogged with foreign materials, such as
dirt, excessive pressure may develop. If the nozzle becomes
partially clogged or restricted, the pump pressure will pulsate.
Clean the nozzle immediately using the nozzle kit supplied and
the following instructions:
1. Shut off the pressure washer and turn off the watersupply.
2. Pull trigger on gun handle to relieve any waterpressure.
3. Disconnect the spray wand from thegun.
4. Remove the high pressure nozzle
11
from the spray wand.
Remove any obstructions with the nozzle cleaning tool
provided and backflush with cleanwater.
5. Direct water supply
14
into nozzle to backflush loosened
particles for 30seconds.
6. Reassemble the nozzle to the wand.
7. Reconnect spray wand to gun and turn on watersupply.
8. Start pressure washer and place spray wand into high
pressure setting totest.
Clean the Water Inlet Filter (Fig. H)
This screen filter should be checked periodically and cleaned
ifnecessary.
1. Remove filter
13
by grasping end and removing it from
water inlet of pump.
2. Clean filter by flushing it with water on bothsides.
3. Re-insert filter into water inlet of pump. NOTE: Cone side
facesout.
NOTE: Do not operate the pressure washer without filter
properly installed.storage
STORAGE
Engine
Consult the Engine Owner’s Manual for manufacturer’s
recommendations forstorage.
To Prevent Fuel-Related Problems
1. Add Ethanol Shield
TM
fuel stabilizer following the
manufacturer’s instructions. When adding a gasoline
stabilizer, fill the fuel tank with fresh gasoline. If only partially
filled, air in the tank will promote fuel deterioration during
storage. If you keep a container of gasoline for refueling, be
sure that it contains only freshgasoline.
2. After adding a gasoline stabilizer, run the engine outdoors
for 10 minutes to be sure that treated gasoline has replaced
the untreated gasoline in thecarburetor.
3. Turn the fuel valve to the OFFposition.
4. Continue to run the engine until it stops from the lack of
fuel in the carburetor fuel bowl. Running time should be less
than 3minutes.
Pump
The manufacturer recommends using SIMPSON
®
/
POWERWASHER
®
Pump Guard or equivalent when storing the
unit for more than 30 days and/or when freezing temperatures
are expected. SIMPSON
®
/ POWERWASHER
®
Pump Guard is
environmentallyfriendly.
NOTE: Using pump guard helps provide proper lubrication to
the internal seals of the pump regardless of temperature or
environment.
NOTICE: Risk of property damage. Use only SIMPSON®
/ POWERWASHER® Pump Guard or equivalent. Other
products could be corrosive and/or contain alcohol which
may cause pumpdamage.
1. Turn off pressure washer and disconnect hoses frompump.
2. Unscrew bottle valve from Pump Guard bottle and
removeseal.
3. Screw bottle valve back ontobottle.
4. Attach bottle to water inlet ofpump.
5. Squeeze bottle to inject contents intopump.
6. With ignition switch off, simultaneously pull starter rope
and squeeze bottle. Repeat until protector fluid exits pump
outlet. NOTE: This step may require twopeople.
SIMPSON
®
is a registered trademarks of the FNA Group, Inc.
POWERWASHER
TM
is a registered trademarks of the FNA Group, Inc.
