Replacement Parts
3A4476B 29
Parts List
Ref. Sprayer Name Part # Description
1 All 17P186 Kit, pump assembly includes 4, 9, 11, 25
3 All 17P554 Filter. pump, 60 mesh, 3 pack
All 17P555 Filter. pump, 100 mesh, 3 pack
4All17P183 Kit, outlet valve repair includes 3 of 4a, 2 of 4b, 2 of 50, 1 of 51
4a All Outlet valve assembly
4b All Outlet valve plug
9 All 17P098 Prime Pump/Spray valve includes 18, 37
11 All 16Y425 O-ring
12 All 17P179 Kit, Smartcontrol with enclosure includes 31, 34, 7 of 37, 52
13 All 17N515 Lid, cup includes 1 of 19
14
All 17A226 FlexLiner, 32 oz. (3-pack)
All 17P212 FlexLiner, 32 oz. (25-pack)
All 17F005 FlexLiner, 42 oz. (3-pack)
All 17P549 FlexLiner, 42 oz. (25-pack)
15
Ultra, Ultimate 17N392 Support, cup, 32 oz.
TC Pro 16W846 Support, cup, 32 oz.
16
17P550 Kit, cup support, lid and plug 32 oz. includes 13, 1 of 14, 15,
17, 1 of 19
17P552 Kit, cup support, lid and plug 42 oz. includes 13, 1 of 14, 15,
17, 1 of 19
17 All 17M879 Plug, cup lid, not shipped with sprayer (not shown)
18 All 17M882 Prime Pump/Spray knob
19 All 17P712 VacuValve cap (3-pack)
20
Ultra 17P664 Kit, label, brand
Ultimate 17P666 Kit, label, brand
TC Pro 17P667 Kit, label, brand
25 All 17P174 Kit, front valve includes 51
29
Ultra, Ultimate 246215 Guard, spray tip, FFLP
TC Pro 17P574 Guard, spray tip, TCP
30
Ultra, Ultimate FFLP514 Spray tip, FFLP 514
TC Pro TCP514 Spray tip, TC P514
31 All 17P235 Kit, enclosure, cover includes 7 of 37
34 All 17P111 Motor, DC
36 All 17P501 Kit, tip seat and seal (5-pack)
37 All 17R614 Screw, cross-head
37a All 128726 Screw, cross-head
38 All 17P474 20V MAX* 2.0Ah Li-ion Compact Battery Pack DEWALT DCB203
39 All 17P475 20V MAX* 2.0Ah Li-ion Battery Charger DEWALT DCB115 (not shown)
40
Ultra, Ultimate 17M883 Case, storage (not shown)
TC Pro 17N194 Case, storage (not shown)
50 All 17M394 O-ring
51 All 125119 O-ring
- - - 24D386 Pump Armor, not shipped with sprayer 4 oz (not shown)
- - - 244168 Pump Armor, not shipped with sprayer 8 oz (not shown)
52 All 17P681 Kit, warning labels (not shown)
53 All 179960 Medical alert Card English, Spanish, French (not shown)
* Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
Replacement Danger and Warning labels, tags, and cards are available at no cost.
