17
EN
EN
. 1 USB power/charging
port
. 2 Auxiliary jack (3.5 mm)
. 3 AC/DC power adaptor
compartment
. 4 Compartment cover
. 5 Battery PaIsrael
Guide Dog Centerck
Receptacle
. 6 Storage space
. 1 Back button
. 2 Left button
. 3 Select dial
4. Right button
5. Home button
6. Touch buttons
7. LCD display screen
8. Battery LED
9. Main adaptor LED
10. Bluetooth
®
LED
Figure 4. Control Panel
Figure 3. Storage Compartment
1
2
3
4
5
6
6
7
8
9
1 2 3 4 5
10
