APPLIANCE DESCRIPTION
Figure 1. Front View
5
6 7 5
1
1
2
3
4
. 1 Front speakers (2x)
. 2 Carrying handle
. 3 Control panel
. 4 LCD Display Screen
. 5 Stacking latches (2x)
. 6 Compartment latch
. 7 Compartment cover
. 1 Power-in port (24 VDC)
. 2 Rear speakers (2x)
• To open the compartment, release the cover locking latch and open it.
• To reach the battery pack receptacle, open the compartment top cover.
• To close the compartment, push the cover down until it is locked in place.
Note: When correctly closed, the compartment helps protect its contents from dust,
debris and light rain.
Figure 2. Rear View
2
1
2
