• To select speed 1(highest torque setting), turn the tool
off and permit it to stop. Slide the speed selector
8
all the
wayforward.
• Speed 2(middle torque and speed setting) is in the
middleposition.
• Speed 3(highest speed setting) is to therear.
If the tool does not change speeds, confirm that the speed
selector is completely engaged in the forward or backposition.
If trouble shifting gears persists, depress and release the trigger
switch and tryagain.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Proper Hand Position (Fig.H)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
Proper hand position requires one hand on the main
handle
15
, with the other hand on the side handle
14
to
control the twisting action of thedrill.
Variable Speed Trigger and Forward/Reverse
Control Button (Fig.A)
The tool is turned on and off by pulling and releasing the
variable speed trigger switch
3
. The farther the trigger switch
is depressed, the higher the speed of the tool. Your tool is
equipped with a brake. The chuck will stop as soon as the
trigger switch is fullyreleased.
A forward/reverse control button
4
determines the rotational
direction of the tool and also serves as a lock-offbutton.
• To select forward rotation (clockwise), release the trigger
switch and depress the forward/reverse control button on
the right side of thetool.
• To select reverse (counterclockwise), depress the forward/
reverse control button on the left side of thetool.
NOTE: The center position of the control button locks the tool
in the off position. When changing the position of the control
button, be sure the trigger isreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start-up. This is normal and
does not indicate aproblem.
tabs
17
on the top and bottom of the gear case. The side
handle is then securely clamped by turning the handle grip
18
clockwise until tight. Be sure to grip the side handle at the far
end on the handle grip to control the tool during astall.
IMPORTANT: Figures D3 and D4 illustrate correct and incorrect
installation of the sidehandle.
Installing a Bit or Accessory into a Keyless
Chuck (Fig.C)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changingacces sories.

WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.

WARNING: The keyless chuck is unlocked after the first
click in the counterclockwise direction with the chuck
sleeve. Operation in the unlocked condition may cause
unintentional opening of the keylesschuck.
To insert a drill bit or other accessory, follow thesesteps.
1. Turn tool off and remove batterypack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 3/4" (19 mm) into the chuck
6
and tighten securely by grasping and rotating the chuck
sleeve
7
clockwise with one hand while holding the tool
with the other. When the chuck is nearly tightened you will
hear a clicking sound. Continue tightening as far as you
can. Your tool is equipped with an automatic spindle lock
mechanism. This allows you to open and close the chuck
with onehand.
4. Be sure to tighten the chuck with one hand on the
chuck sleeve and one hand holding the tool for
maximum tightness. When tightening, do not turn in the
counterclockwisedirection.
5. To release the accessory, repeat steps 1and 2above.
Mode Selection (Fig.A)
The mode selection collar
5
can be used to select the correct
operating mode depending upon the plannedapplication.
To select, rotate the collar until the desired symbol aligns with
thearrow.

WARNING: When the mode selection collar is in the drill,
the drill will not clutch. The drill may stall if overloaded,
causing a suddentwist.
Speed Selection (Fig.A)
The tool features three speed settings for greaterversatility.
NOTE: Do not change speeds when the tool is running.
Always allow the tool to come to a complete stop before
changingspeed.
