DeWalt XR DCD1007 - Maintenance; Optional Accessories

11
ENGLISH
11
encountered, appropriate drill bits capable of withstanding nail
strikes should be used. Work that is apt to splinter should be
backed up with a block ofwood.
Hammerdrilling
IMPORTANT: Use carbide-tipped or masonry bits rated for
percussion drillingonly.
1. Select the desired speed/torque range using the speed
selector
8
to match the speed and torque to the planned
operation. Turn the mode selection collar
5
to the
hammerdrillsymbol.
2. Pull the trigger, applying just enough pressure on the
hammer to keep it from bouncing excessively or "rising" off
the bit.
Recommendations for Hammerdrilling
• Too much force will cause slower drilling speeds,
overheating, and a lower drillingrate.
• A smooth even flow of material indicates the proper
drillingrate.
• Drill straight, keeping the bit at a right angle to the work. Do
not exert side pressure on the bit when drillling as this will
cause clogging of the bit flutes and a slower drillingspeed.
• When drilling deep holes, if the hammer speed starts to
drop off, pull the bit partially out of the hole with tool still
running to help clear debris from thehole.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Electrical shock and mechanical hazard.
Disconnect the electrical appliance from the power source
beforecleaning.

WARNING: To ensure safe and efficient operation,
always keep the electrical appliance and the ventilation
slotsclean.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Ventilation slots can be cleaned using a dry, soft non-metallic
brush and/or a suitable vacuum cleaner. Do not use water or
any cleaning solutions. Wear approved eye protection and an
approved dustmask.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT‑recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Tool Connect™ Chip (Fig. I)
(Optional Application)

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Your tool is Tool Connect™ Chip ready and has a location for
installation of a Tool Connect™ Chip.
Tool Connect™ Chip is an optional application for your
smart device (such as a smart phone or tablet) that connects
the device to utilize the mobile application for inventory
management functions.
Refer to Tool Connect™ Chip Instruction Sheet for
moreinformation.
Installing the Tool Connect™ Chip
1. Remove the retaining screws
23
that hold the Tool
Connect™ Chip protective cover
24
into thetool.
2. Remove the protective cover and insert the Tool Connect™
Chip into the empty pocket
25
.
3. Ensure that the Tool Connect™ Chip is flush with the housing.
Secure it with the retaining screws and tighten thescrews.
4. Refer to Tool Connect™ Chip Instruction Sheet for
furtherinstructions.
Belt Hook and Bit Clip (Fig.A)
Optional Accessories

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool’s belt hook to hang the
tool from a work belt. DO NOT use the belt hook for
tethering or securing the tool to a person or object during
use. DO NOT suspend tool overhead or suspend objects
from the belthook.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing the belt hook or bit
clip, use only the screw
12
that is provided. Be sure to securely
tighten thescrew.
The belt hook
11
and bit clip
13
can be attached to either side
of the tool using only the screw
12
provided, to accommodate
left- or right-handed users. If the belt hook or bit clip is not
desired at all, they can be removed from thetool.
To move the belt hook or bit clip, remove the screw that holds
it in place then reassemble on the opposite side. Be sure to
securely tighten thescrew.
