DeWalt XR DCF850 Original Instructions

ENGLISH
20
IMPORTANT: When attaching or replacing the belt hook or
magnetic bit holder, use only the screw
9
that is provided. Be
sure to securely tighten thescrew.
The belt hook
8
and magnetic bit holder
12
can be attached
to either side of the tool using only the screw
9
provided,
to accommodate left- or right- handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
thetool.
To move belt hook or magnetic bit holder, remove the screw
9
that holds it in place then reassemble on the opposite side. Be
sure to securely tighten thescrew.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.
Proper Hand Position (Fig. A, C)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
Proper hand position requires one hand on the main
handle
10
.
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
1
. To turn the
tool off, release the trigger switch. Your tool is equipped with a
brake. The tool will stop when the trigger switch is fullyreleased.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes orfasteners.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
2
determines the direction of
the tool and also serves as a lock-offbutton.
To select forward rotation, release the trigger switch
1
and
depress the forward/reverse control button
2
on the right side
of thetool.
To select reverse, release the trigger switch
1
and depress
the forward/reverse control button
2
on the left side of the
tool. The centre position of the control button locks the trigger
switch in the off position. When changing the position of the
control button, be sure the trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
Worklights (Fig. A)
There are three worklights
7
located around the 6.35 mm hex
chuck
4
. The worklights are activated when the trigger switch
isdepressed.
When the trigger is released, the worklight will stay illuminated
for up to 20seconds.
NOTE: The worklights are for lighting the immediate work
surface and are not intended to be used as aflashlight.
Mode Selector (Fig. A, D)
Your tool is equipped with a mode selector
11
which allows
you to select one of three modes. Select the mode based on the
application and control the speed of the tool using the variable
speed trigger switch
1
.
Precision Drive (Fig. D)
In addition to normal impacting modes, this tool features the
Precision Drive mode which enables greater control in lighter
applications to avoid damage to materials or fasteners. It is ideal
for light applications such as cabinet hinge screws or machine
screws. Precision Drive mode will work as a screwdriver in light
applications, before hesitating as the screw head reaches the
work piece, and then (if required) start a slow controlled impact
to ensure the head ends perfectlyflush.
NOTE: This mode is for light duty screwdriving applications. If
the tool will not drive a fastener in Precision Mode, please select
mode 2 which will give the additional powerrequired.
DCF850
Mode 1 Precision Drive rpm 0–1000
Mode 2 Normal Impacting rpm 0–2800
Mode 3 High Speed Impacting rpm 0–3250
Quick-Release Chuck (Fig. A, E, F)

WARNING: Use only impact accessories. Non-impact
accessories may break and cause a hazardous condition. Inspect
accessory prior to use to ensure that it con tains nocracks.
NOTE: The chuck accepts 6.35 mm hex accessoriesonly.
Place the forward/reverse button
2
in the lock-off (centre)
position or remove battery pack before changingaccessories.
To install an accessory, fully insert the accessory. The accessory is
locked into place (Fig.E).
To remove an accessory, pull the chuck collar
3
away from the
front of the tool. Remove the accessory (Fig.F).
Usage
Your impact tool generates the following maximum torque:
Cat # Nm
DCF850 206.2

CAUTION: Ensure fastener and/or system will withstand the
level of torque generated by the tool. Excessive torque may cause
breakage and possible personalinjury.
1. Place the accessory into the chuck. Keep the tool pointed
straight at the workpiece.
2. Press switch to start operation. Release the switch to stop
operation. Always check torque with a torque wrench, as the
fastening torque is affected by many factors including the
following:
- Voltage: Low voltage, due to a nearly discharged battery, will
reduce fasteningtorque.
- Socket size: Failure to use the correct socket size will cause a
reduction in fasteningtorque.
- Bolt Size: Larger bolt diameters generally require higher
fastening torque. Fastening torque will also vary according to
length, grade, and torquecoefficient.
- Bolt: Ensure that all threads are free of rust and other debris
to allow proper fasteningtorque.

DeWalt XR DCF850 Specifications

General

Voltage	18V
Impacts per Minute	0-3800 IPM
LED Light	Yes
Anvil Type	1/4-inch hex
Battery Type	Li-Ion
Max Torque	205 Nm
