DeWalt XR Li-Ion DCD790D2 User Manual

32
english
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product development and innovation make
D
e
WALT one of the most reliable partners for professional power tool users.
Technical Data
DCD732 DCD737 DCD790 DCD795
Voltage V
DC
14.4 14.4 18 18
Type 2/11 2/11 2/11 2/11
Battery Type Li-Ion Li-Ion Li-Ion Li-Ion
Power output W 310 310 360 360
No-load speed
1st gear min
-1
0–550 0–550 0–600 0–600
2nd gear min
-1
0–2000 0–2000 0–2000 0–2000
Impact rate
1st gear min
-1
– 0–9500 – 0–10200
2nd gear min
-1
– 0–33200 – 0–34000
Max. torque (hard/soft) Nm 57/19 57/19 60/23 60/23
Chuck capacity mm 1.5–13.0 1.5–13.0 1.5–13.0 1.5–13.0
Maximum drilling capacity
Wood mm 38 38 38 38
Metal mm 13 13 13 13
Masonry mm – 13 – 13
Weight (without battery pack) kg 1.20 1.27 1.20 1.27
Noise values and vibration values (triax vector sum) according to EN60745-2-1, EN60745-2-2:
L
PA
(emission sound pressure level) dB(A) 76 90 76 90
L
WA
(sound power level) dB(A) 87 101 87 101
K (uncertainty for the given sound level) dB(A) 3 3 3 3
Drilling into metal
Vibration emission value a
h,D
= m/s² 2.8 3.3 2.8 3.3
Uncertainty K = m/s² 1.5 1.5 1.5 1.5
Drilling into concrete
Vibration emission value a
h,ID
= m/s² – 23 – 23
Uncertainty K = m/s² – 1.5 – 1.5
Screwdriving
Vibration emission value a
h
= m/s² <2.5 <2.6 <2.5 <2.6
Uncertainty K = m/s² 1.5 1.5 1.5 1.5
BRUSHLESS CORDLESS COMPACT 13 mm (1/2")
DRILL/DRIVER, DCD732, DCD790
BRUSHLESS CORDLESS COMPACT 13 mm (1/2")
DRILL/DRIVER/HAMMERDRILL, DCD737, DCD795
English (original instructions)
