Important safety information to reduce risk of fire injury.
1. Do not install within 10 feet (3 m) of a pool, spa or fountain.
2. There are no serviceable parts inside the power supply unit. DO NOT
DISASSEMBLE.
3. Do not repair or tamper with cord or plug.
4. Do not submerge transformer in water.
5. Do not mount the transformer onto combustible material.
6. Do not connect two or more transformers in parallel.
7. Do not use the transformer with a dimmer switch.
8. Plug the power supply unit directly into a GFCI wet location outlet.
9. For use with low voltage outdoor landscape lighting system only.
10. The maximum output of this transformer is 120 watts. Do not overload
the transformer. Be sure that the total cumulative wattage of all 12 volt
fixtures connected to the transformer is equal to or less than 120 watts.
SAFETY INSTRUCTIONS
The 120 Watt transformer has 120 watt circuits which will power up to 120
watts of light. To make sure the maximum number of fixtures can be safely
connected to this transformer, add up the individual wattage of all the
fixtures. The total wattage of your fixtures must not exceed output capacity
of the 120 Watt transformer.
Being careful when splitting it.
NOT to expose the copper cable.
Remove the landscape cable
insulation 1/2 inch from both
cables and twist ends.
CALCULATE LIGHTING CAPACITY
1. Preparing the Cable
INSTALLATION
CAUTION: This landscape light system must be installed in accordance
with all local codes and ordinances. If you are experiencing problems,
contact a qualified electrician.
