Dexter Laundry SWAY CONTROL - Page 18

-17-
3 RED
Flashes
DSC
Status
Light
Module
Status
Light
Cable
Temporarily
connect the
Purple and
White wire
at ONE brake
location and
verify the
status LED
flashes RED
3 times
LEFT Side
Brake Wires
PURPLE - Brake
Control
WHITE - Ground
Purple
4 RED
Flashes
DSC
Status
Light
Module
Status
Light
Cable
Temporarily
connect the
Pink and
White wire
at ONE brake
location and
verify the
status LED
flashes RED
4 times
RIGHT Side
Brake Wires
PINK - Brake
Control
WHITE - Ground
Pink
Figure 1 Figure 2
Functional Test Procedure
