-7-
DSC Wiring
Trailer Battery
The trailer must be equipped with a full size 12 volt battery. Small,
gel-cell type batteries must not be used with the DSC.
Full Size +12V
Trailer Battery
Break-Away
Switch
-
+
Frame
Ground
Left Front
Electric Brake
Left Rear
Electric Brake
Right Rear
Electric Brake
Right Front
Electric Brake
Must Use
Full Size
Trailer Battery
Dexter
Sway Control
Front
Rear
White
Blue
Blue
Blue
Black
+ Battery
White
Purple
White
Pink
White
Pink
Figure 3
Dexter Sway Control Wiring
