15
EN
7. TORQUE ADJUSTMENT (SEE FIG. G)
(Screw driving force of your drill driver)
The torque is adjusted by rotating the torque adjustment ring. The torque is greater when the torque
adjustment ring is set on a higher setting. The torque is less when the torque adjustment ring is set
on a lower setting.
Make the setting as follows:
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 18 for driving screws into soft and hard material
for heavy drilling
8. AUTOMATIC SPINDLE LOCK (SEE FIG. H)
The automatic spindle lock allows you to use it as a regular screwdriver. You can give an extra twist
to rmly tighten a screw, loosen a very tight screw or continue working when the battery energy has
expired. For manual screwdriver purposes, the chuck is automatically locked when the tool is off.
9. USING THE SIGHT LIGHT
To turn on the light simply press the on/off switch. When you release the on/off switch, the light will be off.
LED lighting increases visibility-great for dark or enclosed area. LED is also a battery capacity
indicator. It will ash when power gets low.
10. DRILLING
When drilling into a hard smooth surface, use a center punch to mark the desired hole location. This
will prevent the drill bit from slipping off center as the hole is started. Hold the tool rmly and place
the tip of the bit at the point to be drilled. Depress the switch trigger to start the tool. Move the drill
bit into the workpiece, applying only enough pressure to keep the bit cutting. Do not force or apply
side pressure to elongate a hole.
Tungsten carbide drill bits should always be used for concrete and masonry. When drilling
in metal, only use HSS drill bits in good condition. Always use a magnetic bit holder (not
included) when using short screwdriver bits. When screw-driving, apply a small quantity of liquid
soap or similar to the screw threads to ease insertion.
11. DISPOSAL OF AN EXHAUSTED BATTERY PACK
To preserve natural resources, please recycle or dispose of the battery pack properly. This
battery pack contains Lithium batteries. Consult your local waste authority for information
regarding available recycling and/or disposal options. Discharge your battery pack by
operating your drill, then remove the battery pack from the drill housing and cover the battery pack
connections with heavy-duty adhesive tape to prevent short circuit and energy discharge. Do not
attempt to open or remove any of the components.
12. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop. Relieve the load on the machine immediately and
allow cooling for approx. 30 seconds at the highest no-load speed.
13. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
When using as intended for the power tool cannot be subject to overload. When the load is too high
or the allowable battery temperature of 75°C is exceeded, the electronic control switches off the
power tool until the temperature is in the optimum temperature range again.
14. PROTECTION AGAINST DEEP DISCHARGING
The Li-Ion battery is protected against deep discharging by the “Discharging Protection System”.
