- 21 -
3.3 Technical specifications
Transmitter
Channel number 2 channels
Frequency 2,4 GHz
Modulation GFSK
Signals Digital signals (in 1024 steps)
Use Car, ship
Undervoltage indicator (LED) yes (under 9V)
PC Link (DSC Port) Jack plug (3.5mm)
Internal charging socket yes
Operating voltage 12V DC (8xAA)
Weight 328g
Dimensions 159 x 99 x 315mm
Receiver
Channel number 3 channels
Frequency 2,4 GHz
Use Car, ship
Modulation GFSK
Resolution 1024 steps
Operating voltage 4.5-6V DC
Weight 5g
Dimensions (LxWxH) 37.6 x 22.3 x 13mm
Antenna length 170mm
Servo (no. 2002)
Metal gears, two ball bearings
Operating voltage 6V
Actuating speed (sec/60°) 0,16sec
Actuating torque 9,0kgcm (88,3Ncm)
Weight 56g
Dimensions (LxWxH) 41,3mm x 20,3mm x 38,7mm
4. CHARGinG tHE bAttERiEs
For ecological and economic reasons, we recommend the use of rechargeable batteries for operating
the remote control set. These can be directly charged in the transmitter using the charging socket
and a suitable charger.
Please follow the separate operating instructions of the battery charger used (not included
in delivery) and the specifications of the battery manufacturer.
Note that, depending on the type of battery used, several complete discharge and charge cycles are
necessary before a brand new (empty) battery supplies its maximum power.
Besides, discharge the NiMH and NiCD rechargeable batteries at regular intervals, since charging a
“half-full” rechargeable battery several times can cause a so-called memory effect. This means that
the rechargeable battery loses the charged part of its capacity. This reduces the operating time of
the model or the transmitter.
Because of the memory effect, NiMH and NiCd batteries should always be fully discharged and
should not be charged even for storage.
Discharge the rechargeable batteries completely when not in use for a long time and charge them
again just before the next use.
