PortEnable
UseGlobalSetting
Terminal Type
Baud Rate
Data Bits
Parity
Stop Bits
Flow Control
Advanced
F1 Help ↑/↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←/→ Select Item Enter Select

SubMenu F10 Save and Exit
InsydeH2O Setup Utility Rev. 5.0
<Enabled>
<Disabled>
<VT_100>
<115200>
<8 Bits>
<None>
<1 Bit>
<None>
When UseGlobalSetting is set to disabled, the screen will appear like shown below:
PortEnable
UseGlobalSetting
Advanced
F1 Help ↑/↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←/→ Select Item Enter Select

SubMenu F10 Save and Exit
InsydeH2O Setup Utility Rev. 5.0
<Enabled>
<Enabled>
COMA to COMF and Pci Serial Port 0:22:3
PortEnable
This field is used to enable or disable the COM port to redirect the console.
UseGlobalSetting
This field is to enable or disable to use global setting. When enabled the global set-
ting, setting of the COM port will be the same as those in Console Redirection section.
When disabled the global setting, setting of the COM port can be configured indepen-
dently in this section.
