DHP 4296449N - Step 7: Slat Installation; Correct Slat Orientation

12
7.1
7.2
SLAT WARNING
Incorrect: Slat curve
facing downwards.
Correct: Slat curve should
be facing upwards.
X
E
7.1 Insert P1 into X;
7.2 Press X into E, repeat the same
procedure for the opposite side of the bed.
with a new P1 and X.
Follow the same procedures going
backwards for every row of slats.
P1
X
P1
X
E
E
