DHP 5458196 - Step 5: Install Slat Spacers and Ladder

DETAIL 1
DETAIL 2
11 /15
5
Attach the SLAT SPACERS (N) between SLATS (Q & K) as shown in DETAIL (1).
Attach the LADDER (L) to the LADDER SIDE RAIL (H) with the BOLTS (1) and NUTS (7) as shown in DETAIL (2).
Hardware Required
x2
x2
7
1
Q
Q
N
N
K
K
K
K
H
H
1
1
L
7
7
L
