DHP 5458196 - Step 4: Install Slats

AFTER CURRENT ASSEMBLING
(TOP VIEW)
10 /15
4
Carefully attach the SLATS (Q & K) to the UPPER SIDE RAILS (G & H), by using two SLATS (Q) at the extremist ends of the
UPPER SIDE RAILS (G & H), and using 18 SLATS (K) in-between. Lock the SLATS (Q & K) into place with 44 PLASTIC PLUGS
(R), as shown below.
G
K
K
K
R
R
R
Q
Use SLAT (Q) at this side
Use SLAT (Q) at this side
Q
Q
K
K
B34545819600
K
Q
Q
O
O
O
