DHP 5458196 - Step 3: Attach Guard Rails

DETAIL 1
DETAIL 2
9 /15
3
Attach the GUARD RAILS (E & F) to the LEG POSTS (A, B & D) with the BOLTS (2) as shown in detail (1). Attach the GUARD
RAILS (E & F) to the SIDE RAILS (G & H) with the BOLTS (9) as shown in detail (2).
Hardware Required
x 6
x3
2
2
2
